固定电感器
| 图片 | 制造商型号 | 库存情况 | 数量 | 数据手册 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CTM1F-820K82UH AXIAL MOLDED INDUCTOR Central Technologies |
192 |
|
数据手册 |
CTM1F | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 82 µH | ±10% | 88 mA | - | Unshielded | 7.3Ohm Max | 50 @ 2.5MHz | 14MHz | - | -55°C ~ 105°C | 2.5 MHz | - | Through Hole | Axial | 0.095" Dia x 0.250" L (2.41mm x 6.35mm) | - |
|
|
CTM1F-R39K.39UH AXIAL MOLDED INDUCTOR Central Technologies |
184 |
|
数据手册 |
CTM1F | Axial | Tape & Reel (TR) | Active | Molded | Phenolic | 390 nH | ±10% | 700 mA | - | Unshielded | 300mOhm Max | 30 @ 25MHz | 365MHz | - | -55°C ~ 105°C | 25 MHz | - | Through Hole | Axial | 0.095" Dia x 0.250" L (2.41mm x 6.35mm) | - |
|
|
CTM1F-181K180UH AXIAL MOLDED INDUCTOR Central Technologies |
147 |
|
数据手册 |
CTM1F | Axial | Tape & Reel (TR) | Active | Molded | Ferrite | 180 µH | ±10% | 57 mA | - | Unshielded | 17Ohm Max | 30 @ 790kHz | 10MHz | - | -55°C ~ 105°C | 790 kHz | - | Through Hole | Axial | 0.095" Dia x 0.250" L (2.41mm x 6.35mm) | - |
|
CTCDRH104RF-3R83.8 SMD SHIELDED POWER INDUCTOR Central Technologies |
1,580 |
|
数据手册 |
CTCDRH104RF | Nonstandard | Tape & Reel (TR) | Active | - | - | 3.8 µH | ±30% | - | 6A | Shielded | 15mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.394" L x 0.394" W (10.00mm x 10.00mm) | 0.157" (4.00mm) |
|
|
CTCDRH104RF-15015 SMD SHIELDED POWER INDUCTOR Central Technologies |
1,160 |
|
数据手册 |
CTCDRH104RF | Nonstandard | Tape & Reel (TR) | Active | - | - | 15 µH | ±30% | - | 3.6A | Shielded | 50mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.394" L x 0.394" W (10.00mm x 10.00mm) | 0.157" (4.00mm) |
|
|
CTCDRH104RF-5R25.2 SMD SHIELDED POWER INDUCTOR Central Technologies |
1,008 |
|
数据手册 |
CTCDRH104RF | Nonstandard | Tape & Reel (TR) | Active | - | - | 5.2 µH | ±30% | - | 5.7A | Shielded | 22mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.394" L x 0.394" W (10.00mm x 10.00mm) | 0.157" (4.00mm) |
|
|
CTCDRH104RF-10010 SMD SHIELDED POWER INDUCTOR Central Technologies |
781 |
|
数据手册 |
CTCDRH104RF | Nonstandard | Tape & Reel (TR) | Active | - | - | 10 µH | ±30% | - | 4.4A | Shielded | 35mOhm Max | - | - | - | -40°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.394" L x 0.394" W (10.00mm x 10.00mm) | 0.157" (4.00mm) |
|
CTAF05TJSMD AIR CORE INDUCTOR Central Technologies |
330 |
|
数据手册 |
ctaf | - | Tape & Reel (TR) | Active | Wirewound | - | 18.5 nH | ±5% | - | - | - | 3.9mOhm | - | 2.5GHz | - | -40°C ~ 85°C | - | - | Surface Mount | - | - | - |
|
CTDT1608CF-22322UH SMD SHIELDED POWR INDUCTOR Central Technologies |
4,347 |
|
数据手册 |
CTDT1608F | Nonstandard | Tape & Reel (TR) | Active | - | - | 22 µH | ±20% | 500 mA | - | Shielded | 160mOhm Max | - | - | - | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.259" L x 0.175" W (6.58mm x 4.45mm) | 0.115" (2.92mm) |
|
|
CTDT1608CF-10310UH SMD SHIELDED POWR INDUCTOR Central Technologies |
2,248 |
|
数据手册 |
CTDT1608F | Nonstandard | Tape & Reel (TR) | Active | - | - | 10 µH | ±20% | 700 mA | - | Shielded | 100mOhm Max | - | - | - | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.259" L x 0.175" W (6.58mm x 4.45mm) | 0.115" (2.92mm) |
