固定电感器
| 图片 | 制造商型号 | 库存情况 | 数量 | 数据手册 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CTH6EF-100K10UH MINI AXL P-LINE INDUCTR Central Technologies |
370 |
|
数据手册 |
CTH6F | Axial | Tape & Reel (TR) | Active | Wirewound | - | 10 µH | ±10% | 1.5 A | 970mA | Unshielded | 100mOhm Max | - | 25MHz | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | Axial | 0.160" Dia x 0.500" L (4.06mm x 12.70mm) | - |
|
|
CTH6EF-222K2200UH MINI AXL P-LINE INDUCTOR Central Technologies |
352 |
|
数据手册 |
CTH6F | Axial | Tape & Reel (TR) | Active | Wirewound | - | 2.2 mH | ±10% | 100 mA | 64mA | Unshielded | 19Ohm Max | - | 640kHz | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | Axial | 0.160" Dia x 0.500" L (4.06mm x 12.70mm) | - |
|
|
CTH6EF-470K47UH MINI AXL P-LINE INDUCTOR Central Technologies |
294 |
|
数据手册 |
CTH6F | Axial | Tape & Reel (TR) | Active | Wirewound | - | 47 µH | ±10% | 760 mA | 430mA | Unshielded | 350mOhm Max | - | 6MHz | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | Axial | 0.160" Dia x 0.500" L (4.06mm x 12.70mm) | - |
|
|
CTH6EF-331K330UH MINI AXL P-LINE INDUCTOR Central Technologies |
174 |
|
数据手册 |
CTH6F | Axial | Tape & Reel (TR) | Active | Wirewound | - | 330 µH | ±10% | 290 mA | 170mA | Unshielded | 2.4Ohm Max | - | 1.9MHz | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | Axial | 0.160" Dia x 0.500" L (4.06mm x 12.70mm) | - |
|
CTGS105F-121K120UH SMD UNSHLD POWER INDUCTOR Central Technologies |
1,000 |
|
数据手册 |
CTGS105F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 120 µH | ±10% | - | 890mA | Unshielded | 400mOhm Max | - | - | - | -40°C ~ 105°C | 1 kHz | - | Surface Mount | - | 0.394" L x 0.354" W (10.00mm x 9.00mm) | 0.228" (5.80mm) |
|
CTCDRH74F-331M330UH SMD SHIELDED POWR INDUCTOR Central Technologies |
1,995 |
|
数据手册 |
CTCDRH74F | Nonstandard | Tape & Reel (TR) | Active | - | - | 330 µH | ±20% | - | 320mA | Shielded | 1.9Ohm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.287" L x 0.287" W (7.30mm x 7.30mm) | 0.177" (4.50mm) |
|
CT916CYF-101MSMD SHIELDED POWER INDUCTOR Central Technologies |
1,505 |
|
数据手册 |
ct916cyf | - | Tape & Reel (TR) | Active | - | - | 100 µH | ±20% | - | - | - | 397mOhm | - | - | - | -40°C ~ 85°C | - | - | Surface Mount | - | - | - |
|
CT187LYF-272JRAD LEADED FIXED SHLDED INDUCTOR Central Technologies |
1,474 |
|
数据手册 |
ct187lyf | - | Bulk | Active | - | - | 2.7 mH | ±5% | - | - | - | 13Ohm | - | 800kHz | - | -55°C ~ 125°C | - | - | Through Hole | - | - | - |
|
|
CT187LYF-822KRAD LEADED FIXED SHLDED INDUCTOR Central Technologies |
800 |
|
数据手册 |
ct187lyf | - | Bulk | Active | - | - | 8.2 mH | ±10% | - | - | - | 26Ohm | - | 500kHz | - | -55°C ~ 125°C | - | - | Through Hole | - | - | - |
|
|
CT187LYF-822JRAD LEADED FIXED SHLDED INDUCTOR Central Technologies |
800 |
|
数据手册 |
ct187lyf | - | Bulk | Active | - | - | 8.2 mH | ±5% | - | - | - | 26Ohm | - | 500kHz | - | -55°C ~ 125°C | - | - | Through Hole | - | - | - |
