场效应晶体管（FETs）、MOSFETs
| 制造商 | 系列 | 封装/外壳 | 包装 | 产品状态 | FET 类型 | 技术 | 漏极到源极电压 (Vdss) | 电流 - 连续漏极 (Id) @ 25°C | 驱动电压（最大导通电阻，最小导通电阻） | 导通电阻 (Rds On)（最大值）@ Id, Vgs | 栅极阈值电压 (Vgs(th)）（最大值）@ Id | 栅极电荷 (Qg)（最大值）@ Vgs | 栅极电压 (Vgs)（最大值） | 输入电容 (Ciss)（最大值）@ Vds | FET 特性 | 功耗（最大值） | 工作温度 | 等级 | 认证 | 安装类型 | 供应商设备封装 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
全部应用
全部重置
结果
| 图片 | 制造商型号 | 库存情况 | 价格 | 数量 | 数据手册 | 系列 | 封装/外壳 | 包装 | 产品状态 | FET 类型 | 技术 | 漏极到源极电压 (Vdss) | 电流 - 连续漏极 (Id) @ 25°C | 驱动电压（最大导通电阻，最小导通电阻） | 导通电阻 (Rds On)（最大值）@ Id, Vgs | 栅极阈值电压 (Vgs(th)）（最大值）@ Id | 栅极电荷 (Qg)（最大值）@ Vgs | 栅极电压 (Vgs)（最大值） | 输入电容 (Ciss)（最大值）@ Vds | FET 特性 | 功耗（最大值） | 工作温度 | 等级 | 认证 | 安装类型 | 供应商设备封装 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TPN4R203NC,L1QMOSFET N CH 30V 23A 8TSON-ADV Toshiba Semiconductor and Storage |
8,862 | - |
|
数据手册 |
U-MOSVIII | 8-PowerVDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 30 V | 23A (Ta) | 4.5V, 10V | 4.2mOhm @ 11.5A, 10V | 2.3V @ 200µA | 24 nC @ 10 V | ±20V | 1370 pF @ 15 V | - | 700mW (Ta), 22W (Tc) | 150°C (TJ) | - | - | Surface Mount | 8-TSON Advance (3.1x3.1) |
|
TK14A45D(STA4,Q,M)MOSFET N-CH 450V 14A TO220SIS Toshiba Semiconductor and Storage |
8,724 | - |
|
数据手册 |
- | TO-220-3 Full Pack | Tube | Last Time Buy | N-Channel | MOSFET (Metal Oxide) | 450 V | 14A | - | 340mOhm @ 7A, 10V | - | - | - | - | - | - | - | - | - | Through Hole | TO-220SIS |
.jpg)
|
TPCA8010-H(TE12L,QMOSFET N-CH 200V 5.5A 8SOP Toshiba Semiconductor and Storage |
5,244 | - |
|
数据手册 |
π-MOSV | 8-PowerVDFN | Tape & Reel (TR) | Obsolete | N-Channel | MOSFET (Metal Oxide) | 200 V | 5.5A (Ta) | 10V | 450mOhm @ 2.7A, 10V | 4V @ 1mA | 10 nC @ 10 V | ±20V | 600 pF @ 10 V | - | 1.6W (Ta), 45W (Tc) | 150°C (TJ) | - | - | Surface Mount | 8-SOP Advance (5x5) |
|
TK14A65W5,S5XMOSFET N-CH 650V 13.7A TO220SIS Toshiba Semiconductor and Storage |
2,110 | - |
|
数据手册 |
DTMOSIV | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 650 V | 13.7A (Ta) | 10V | 300mOhm @ 6.9A, 10V | 4.5V @ 690µA | 40 nC @ 10 V | ±30V | 1300 pF @ 300 V | - | 40W (Tc) | 150°C (TJ) | - | - | Through Hole | TO-220SIS |
|
TPC8109(TE12L)MOSFET P-CH 30V 10A 8-SOP Toshiba Semiconductor and Storage |
6,917 | - |
|
数据手册 |
- | 8-SOIC (0.173", 4.40mm Width) | Cut Tape (CT) | Obsolete | P-Channel | MOSFET (Metal Oxide) | 30 V | 10A (Ta) | - | 20mOhm @ 5A, 10V | 2V @ 1mA | 45 nC @ 10 V | - | 2260 pF @ 10 V | - | - | - | - | - | Surface Mount | 8-SOP (5.5x6.0) |
|
TK2R4E08QM,S1XUMOS10 TO-220AB 80V 2.4MOHM Toshiba Semiconductor and Storage |
7,517 | - |
|
数据手册 |
U-MOSX-H | TO-220-3 | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 80 V | 120A (Tc) | 6V, 10V | 2.44mOhm @ 50A, 10V | 3.5V @ 2.2mA | 178 nC @ 10 V | ±20V | 13000 pF @ 40 V | - | 300W (Tc) | 175°C | - | - | Through Hole | TO-220 |
|
|
TK20A25D,S5Q(MMOSFET N-CH 250V 20A TO220SIS Toshiba Semiconductor and Storage |
9,533 | - |
|
数据手册 |
π-MOSVII | TO-220-3 Full Pack | Tube | Obsolete | N-Channel | MOSFET (Metal Oxide) | 250 V | 20A (Ta) | 10V | 100mOhm @ 10A, 10V | 3.5V @ 1mA | 55 nC @ 10 V | ±20V | 2550 pF @ 100 V | - | 45W (Tc) | 150°C (TJ) | - | - | Through Hole | TO-220SIS |
|
|
TK16A60W,S4XMOSFET N-CH 600V 15.8A TO220 Toshiba Semiconductor and Storage |
9,160 | - |
|
数据手册 |
DTMOSIV | TO-220-3 Full Pack | Tube | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 15.8A (Ta) | 10V | 190mOhm @ 7.9A, 10V | 3.7V @ 790µA | 40 nC @ 10 V | ±30V | 1350 pF @ 300 V | - | 40W (Tc) | - | - | - | Through Hole | TO-220SIS |
|
TK25V60X,LQMOSFET N-CH 600V 25A 4DFN Toshiba Semiconductor and Storage |
7,330 | - |
|
数据手册 |
DTMOSIV-H | 4-VSFN Exposed Pad | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 600 V | 25A (Ta) | 10V | 135mOhm @ 7.5A, 10V | 3.5V @ 1.2mA | 40 nC @ 10 V | ±30V | 2400 pF @ 300 V | - | 180W (Tc) | 150°C | - | - | Surface Mount | 4-DFN-EP (8x8) |
|
TPH1110ENH,L1QMOSFET N-CH 200V 7.2A 8SOP Toshiba Semiconductor and Storage |
4,819 | - |
|
数据手册 |
U-MOSVIII-H | 8-PowerVDFN | Tape & Reel (TR) | Active | N-Channel | MOSFET (Metal Oxide) | 200 V | 7.2A (Ta) | 10V | 114mOhm @ 3.6A, 10V | 4V @ 200µA | 7 nC @ 10 V | ±20V | 600 pF @ 100 V | - | 1.6W (Ta), 42W (Tc) | 150°C (TJ) | - | - | Surface Mount | 8-SOP Advance (5x5) |
