散热器
| 图片 | 制造商型号 | 库存情况 | 数量 | 数据手册 | 系列 | 包装 | 产品状态 | 类型 | 冷却封装 | 附件方式 | 形状 | 长度 | 宽度 | 直径 | Fin 高度 | 功耗 @ 温升 | 热阻 @ 强制气流 | 热阻 @ 自然对流 | 材质 | 材料表面处理 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
625-35ABHEATSINK FOR 25MM BGA |
348 |
|
数据手册 |
625 | Bulk | Active | Top Mount | BGA | Thermal Tape, Adhesive (Included) | Square, Pin Fins | 0.984" (25.00mm) | 0.984" (25.00mm) | - | 0.350" (8.89mm) | - | 13.10°C/W @ 200 LFM | - | Aluminum | Black Anodized |
|
|
657-10ABPEHEATSINK TO-220 W/PINS BLK 1" |
807 |
|
数据手册 |
657 | Bulk | Active | Board Level, Vertical | TO-218, TO-220, TO-247 | Bolt On and PC Pin | Rectangular, Fins | 1.000" (25.40mm) | 1.650" (41.91mm) | - | 1.000" (25.40mm) | 6.0W @ 41°C | 3.70°C/W @ 200 LFM | - | Aluminum | Black Anodized |
|
|
288-1ABEHEATSINK FOR TO220 |
3,312 |
|
数据手册 |
288 | Bulk | Active | Board Level, Vertical | TO-220 | Bolt On and PC Pin | Rectangular, Fins | 1.250" (31.75mm) | 0.875" (22.22mm) | - | 0.215" (5.46mm) | 4.0W @ 85°C | 12.00°C/W @ 600 LFM | 21.20°C/W | Aluminum | Black Anodized |
|
|
HSB32-232318HEAT SINK, BGA, 23 X 23 X 18 MM, |
615 |
|
数据手册 |
HSB | Box | Active | Top Mount | BGA | Adhesive (Not Included) | Square, Pin Fins | 0.906" (23.00mm) | 0.906" (23.00mm) | - | 0.709" (18.00mm) | 5.9W @ 75°C | 4.40°C/W @ 200 LFM | 12.67°C/W | Aluminum Alloy | Black Anodized |
|
|
628-25ABHEATSINK FOR 45MM BGA |
2,991 |
|
数据手册 |
628 | Bulk | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Thermal Tape, Adhesive (Not Included) | Square, Pin Fins | 1.750" (44.45mm) | 1.700" (43.18mm) | - | 0.250" (6.35mm) | 4.5W @ 80°C | 7.00°C/W @ 300 LFM | - | Aluminum | Black Anodized |
|
|
624-35ABHEATSINK FOR 21MM BGA |
5,444 |
|
数据手册 |
624 | Bulk | Active | Top Mount | BGA | Thermal Tape, Adhesive (Not Included) | Square, Pin Fins | 0.827" (21.00mm) | 0.827" (21.00mm) | - | 0.350" (8.89mm) | - | 15.00°C/W @ 400 LFM | - | Aluminum | Black Anodized |
|
|
HSB33-272710HEAT SINK, BGA, 27 X 27 X 10 MM, |
1,044 |
|
数据手册 |
HSB | Box | Active | Top Mount | BGA | Adhesive (Not Included) | Square, Pin Fins | 1.063" (27.00mm) | 1.063" (27.00mm) | - | 0.394" (10.00mm) | 4.4W @ 75°C | 5.30°C/W @ 200 LFM | 17.22°C/W | Aluminum Alloy | Black Anodized |
|
|
657-20ABPNEHEATSINK TO-220 W/PINS BLK 2" |
1,000 |
|
数据手册 |
657 | Bulk | Active | Board Level, Vertical | TO-218, TO-220, TO-247 | Bolt On and PC Pin | Rectangular, Fins | 1.000" (25.40mm) | 1.650" (41.91mm) | - | 2.000" (50.80mm) | 6.0W @ 32°C | 2.90°C/W @ 200 LFM | - | Aluminum | Black Anodized |
|
|
659-65ABHEATSINK EXTRUSION 37MM |
759 |
|
数据手册 |
659 | Bulk | Active | Top Mount | BGA | Thermal Tape, Adhesive (Included) | Square, Pin Fins | 1.450" (36.83mm) | 1.450" (36.83mm) | - | 0.650" (16.51mm) | 2.0W @ 20°C | 1.50°C/W @ 600 LFM | - | Aluminum | Black Anodized |
|
|
624-60ABHEATSINK FOR 21MM BGA |
521 |
|
数据手册 |
624 | Bulk | Active | Top Mount | BGA | Thermal Tape, Adhesive (Not Included) | Square, Pin Fins | 0.827" (21.00mm) | 0.827" (21.00mm) | - | 0.600" (15.24mm) | - | 1.00°C/W @ 400 LFM | - | Aluminum | Black Anodized |
|
|
625-60ABHEATSINK FOR 25MM BGA |
329 |
|
数据手册 |
625 | Bulk | Active | Top Mount | BGA | Thermal Tape, Adhesive (Included) | Square, Pin Fins | 0.984" (25.00mm) | 0.984" (25.00mm) | - | 0.600" (15.24mm) | - | 8.00°C/W @ 200 LFM | - | Aluminum | Black Anodized |
|
|
628-35ABHEATSINK FOR 45MM BGA |
1,997 |
|
数据手册 |
628 | Bulk | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Thermal Tape, Adhesive (Included) | Square, Pin Fins | 1.750" (44.45mm) | 1.700" (43.18mm) | - | 0.350" (8.89mm) | 3.0W @ 50°C | 10.00°C/W @ 150 LFM | - | Aluminum | Black Anodized |
|
ATS-PCBT1086HEATSINK TO-220 W/TAB BLACK |
989 |
|
数据手册 |
- | Bulk | Active | Board Level, Vertical | TO-220 | Bolt On and PC Pin | Rectangular, Fins | 1.250" (31.75mm) | 0.875" (22.22mm) | - | 0.250" (6.35mm) | - | 9.50°C/W @ 200 LFM | 22.00°C/W | Aluminum | Black Anodized |
|
|
627-15ABPEHEATSINK FOR TO218/TO220 |
410 |
|
数据手册 |
627 | Bulk | Active | Board Level, Vertical | TO-218, TO-220, TO-247 | Bolt On and PC Pin | Rectangular, Fins | 0.500" (12.70mm) | 1.375" (34.93mm) | - | 1.500" (38.10mm) | 6.0W @ 65°C | 5.50°C/W @ 200 LFM | - | Aluminum | Black Anodized |
|
|
626-20ABPEHEATSINK FOR TO218/TO220 |
186 |
|
数据手册 |
626 | Bulk | Active | Board Level, Vertical | TO-218, TO-220, TO-247 | Bolt On and PC Pin | Rectangular, Fins | 0.500" (12.70mm) | 1.375" (34.93mm) | - | 2.000" (50.80mm) | 6.0W @ 55°C | 4.70°C/W @ 200 LFM | - | Aluminum | Black Anodized |
|
|
657-25ABPNEHEATSINK TO-220 W/PINS BLK 2.5" |
970 |
|
数据手册 |
657 | Bulk | Active | Board Level, Vertical | TO-218, TO-220, TO-247 | Bolt On and PC Pin | Rectangular, Fins | 1.000" (25.40mm) | 1.650" (41.91mm) | - | 2.500" (63.50mm) | 6.0W @ 25°C | 2.70°C/W @ 200 LFM | - | Aluminum | Black Anodized |
|
|
655-26ABHEATSINK FOR 40MM BGA |
3,946 |
|
数据手册 |
655 | Bulk | Active | Top Mount | Assorted (BGA, LGA, CPU, ASIC...) | Thermal Tape, Adhesive (Not Included) | Square, Pin Fins | 1.600" (40.64mm) | 1.600" (40.64mm) | - | 0.260" (6.60mm) | 5.0W @ 60°C | 3.00°C/W @ 500 LFM | - | Aluminum | Black Anodized |
|
|
677-10ABPEHEATSINK |
1,988 |
|
数据手册 |
677 | Bulk | Active | Board Level, Vertical | TO-218, TO-220, TO-247, Multiwatt | Bolt On and PC Pin | Rectangular, Fins | 1.000" (25.40mm) | 1.650" (41.91mm) | - | 1.000" (25.40mm) | - | 3.10°C/W @ 200 LFM | - | Aluminum | Black Anodized |
|
|
HSB41-303014PHEAT SINK, BGA, 30 X 30 X 10 MM, |
410 |
|
数据手册 |
HSB | Box | Active | Top Mount | BGA | Push Pin | Square, Pin Fins | 1.181" (30.00mm) | 1.181" (30.00mm) | - | 0.551" (14.00mm) | 5.9W @ 75°C | 4.30°C/W @ 200 LFM | 12.63°C/W | Aluminum Alloy | Black Anodized |
|
|
HSB39-252509PHEAT SINK, BGA, 25 X 25 X 9 MM, |
341 |
|
数据手册 |
HSB | Box | Active | Top Mount | BGA | Push Pin | Square, Pin Fins | 0.984" (25.00mm) | 0.984" (25.00mm) | - | 0.354" (9.00mm) | 4.3W @ 75°C | 6.30°C/W @ 200 LFM | 17.53°C/W | Aluminum Alloy | Black Anodized |
