直流直流转换器（DC DC Converters）
| 图片 | 制造商型号 | 库存情况 | 数量 | 数据手册 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 输出数量 | 电压 - 输入（最小） | 电压 - 输入（最大） | 电压 - 输出 1 | 电压 - 输出 2 | 电压 - 输出 3 | 电压 - 输出 4 | 电流 - 输出（最大值） | 功率（瓦特） | 电压 - 隔离 | 应用 | 特性 | 工作温度 | 效率 | 等级 | 认证 | 安装类型 | 供应商设备封装 | 控制特性 | 认证机构 | 标准编号 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
JHM3012S1230W PCB 9-18VDC INPUT 2:1 MEDICA XP Power |
1,000 |
|
数据手册 |
JHM30 (30W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 9V | 18V | 12V | - | - | - | 2.5A | 30 W | 4 kV | Medical | Adjustable Output, Remote On/Off | -40°C ~ 80°C (With Derating) | 88% | - | - | Through Hole | - | - | CB, CE, TUV, UKCA, UL | 60601-1 |
|
|
JHM3024S1230W PCB 18-36VDC INPUT 2:1 MEDIC XP Power |
4,737 |
|
数据手册 |
JHM30 (30W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 18V | 36V | 12V | - | - | - | 2.5A | 30 W | 4 kV | Medical | Adjustable Output, Remote On/Off | -40°C ~ 80°C (With Derating) | 88% | - | - | Through Hole | - | - | CB, CE, TUV, UKCA, UL | 60601-1 |
|
|
JHM3012S0530W PCB 9-18VDC INPUT 2:1 MEDICA XP Power |
3,684 |
|
数据手册 |
JHM30 (30W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 9V | 18V | 5V | - | - | - | 6A | 30 W | 4 kV | Medical | Adjustable Output, Remote On/Off | -40°C ~ 80°C (With Derating) | 88% | - | - | Through Hole | - | - | CB, CE, TUV, UKCA, UL | 60601-1 |
|
|
JHM3024S1530W PCB 18-36VDC INPUT 2:1 MEDIC XP Power |
3,209 |
|
数据手册 |
JHM30 (30W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 18V | 36V | 15V | - | - | - | 2A | 30 W | 4 kV | Medical | Adjustable Output, Remote On/Off | -40°C ~ 80°C (With Derating) | 89% | - | - | Through Hole | - | - | CB, CE, TUV, UKCA, UL | 60601-1 |
|
|
JHM3012S1530W PCB 9-18VDC INPUT 2:1 MEDICA XP Power |
3,996 |
|
数据手册 |
JHM30 (30W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 9V | 18V | 15V | - | - | - | 2A | 30 W | 4 kV | Medical | Adjustable Output, Remote On/Off | -40°C ~ 80°C (With Derating) | 89% | - | - | Through Hole | - | - | CB, CE, TUV, UKCA, UL | 60601-1 |
|
|
JHM3024S0530W PCB 18-36VDC INPUT 2:1 MEDIC XP Power |
1,352 |
|
数据手册 |
JHM30 (30W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 18V | 36V | 5V | - | - | - | 6A | 30 W | 4 kV | Medical | Adjustable Output, Remote On/Off | -40°C ~ 80°C (With Derating) | 88% | - | - | Through Hole | - | - | CB, CE, TUV, UKCA, UL | 60601-1 |
|
ICH7524S15DC DC CONVERTER 15V 75W XP Power |
4,264 |
|
数据手册 |
ICH (200W) | 9-DIP Module | Box | Active | Isolated Module | 1 | 18V | 36V | 15V | - | - | - | 5A | 75 W | 1.5 kV | ITE (Commercial) | Remote On/Off, OVP, SCP | -40°C ~ 100°C | 85% | - | - | Through Hole | - | Enable, Active High | - | 62368-1 |
|
QSB10048S05DC DC CONVERTER 5V 100W XP Power |
2,932 |
|
数据手册 |
QSB (100W) | 8-DIP Module | Box | Active | Isolated Module | 1 | 18V | 75V | 5V | - | - | - | 20A | 100 W | 1.5 kV | ITE (Commercial) | Remote On/Off, OCP, OTP, OVP, SCP | -40°C ~ 100°C | 88% | - | - | Through Hole | - | Enable, Active High | - | - |
|
|
RDF15072S2414-160VDC I/P 24VDC O/P XP Power |
2,799 |
|
数据手册 |
RDF150 (150W) | Half Brick | Box | Active | Isolated Module | 1 | 14V | 160V | 24V | - | - | - | 6.25A | 150 W | 3 kV | ITE (Commercial), Railway | Adjustable Output, Remote On/Off, Remote Sense | -40°C ~ 100°C (With Derating) | 89% | - | - | Through Hole | Half Brick | Enable, Active High | CE, EN, UKCA, UL | 50155; 62368-1 |
|
MTC0528S05DC DC CONVERTER 5V 5W XP Power |
4,360 |
|
数据手册 |
MTC (5W) | 12-DIP Module, 9 Leads | Box | Active | Isolated Module | 1 | 15.5V | 40V | 5V | - | - | - | 800mA | 5 W | 1.5 kV | ITE (Commercial) | OCP, OTP, OVP | -40°C ~ 100°C | 77% | - | - | Through Hole | - | - | - | - |
