三端双向可控硅、SCR 输出光隔离器
| 图片 | 制造商型号 | 库存情况 | 数量 | 数据手册 | 系列 | 封装/外壳 | 包装 | 产品状态 | 输出类型 | 零交叉电路 | 通道数 | 电压 - 隔离 | 电压 - 关断状态 | 静态 dV/dt（最小值） | 电流 - LED 触发 (Ift)（最大值） | 电流 - 导通状态 (It (RMS))（最大值） | 电流 - 保持 (Ih) | 开启时间 | 电压 - 正向 (Vf)（典型值） | 电流 - 直流正向（If）（最大值） | 工作温度 | 安装类型 | 供应商设备封装 | 认证机构 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
H11J36PIN RANDOM PHASE TRIAC, OPTOCOU |
3,127 |
|
数据手册 |
H11J | 6-DIP (0.300", 7.62mm) | Tube | Active | Triac | No | 1 | 5300Vrms | 250 V | 10V/µs (Typ) | 10mA | - | 100µA | - | 1.2V | 50 mA | -40°C ~ 100°C | Through Hole | 6-DIP | UL, VDE |
|
|
H11J16PIN RANDOM PHASE TRIAC, OPTOCOU |
1,118 |
|
数据手册 |
H11J | 6-DIP (0.300", 7.62mm) | Tube | Active | Triac | No | 1 | 5300Vrms | 250 V | 10V/µs (Typ) | 10mA | - | 100µA | - | 1.2V | 50 mA | -40°C ~ 100°C | Through Hole | 6-DIP | UL, VDE |
|
MOC30116PIN RANDOM PHASE TRIAC, OPTOCOU |
3,210 |
|
数据手册 |
MOC301 | 6-DIP (0.300", 7.62mm) | Tube | Active | Triac | No | 1 | 5300Vrms | 250 V | 10V/µs (Typ) | 10mA | - | 100µA (Typ) | - | 1.2V | 50 mA | -40°C ~ 100°C | Through Hole | 6-DIP | UL, VDE |
|
MOC30106PIN RANDOM PHASE TRIAC, OPTOCOU |
3,698 |
|
数据手册 |
MOC301 | 6-DIP (0.300", 7.62mm) | Tube | Active | Triac | No | 1 | 5300Vrms | 250 V | 10V/µs (Typ) | 15mA | - | 100µA (Typ) | - | 1.2V | 50 mA | -40°C ~ 100°C | Through Hole | 6-DIP | UL, VDE |
|
MOC30206PIN RANDOM PHASE TRIAC, OPTOCOU |
3,859 |
|
数据手册 |
MOC302 | 6-DIP (0.300", 7.62mm) | Tube | Active | Triac | No | 1 | 5000Vrms | 400 V | 10V/µs (Typ) | 30mA | - | 100µA | - | 1.2V | 50 mA | -40°C ~ 100°C | Through Hole | 6-DIP | UL, VDE |
|
|
MOC30236PIN RANDOM PHASE TRIAC, OPTOCOU |
3,202 |
|
数据手册 |
MOC302 | 6-DIP (0.300", 7.62mm) | Tube | Active | Triac | No | 1 | 5000Vrms | 400 V | 10V/µs (Typ) | 5mA | - | 100µA | - | 1.2V | 50 mA | -40°C ~ 100°C | Through Hole | 6-DIP | UL, VDE |
|
|
H11J46PIN RANDOM PHASE TRIAC, OPTOCOU |
3,433 |
|
数据手册 |
H11J | 6-DIP (0.300", 7.62mm) | Tube | Active | Triac | No | 1 | 5300Vrms | 250 V | 10V/µs (Typ) | 15mA | - | 100µA | - | 1.2V | 50 mA | -40°C ~ 100°C | Through Hole | 6-DIP | UL, VDE |
|
MOC30126PIN RANDOM PHASE TRIAC, OPTOCOU |
2,558 |
|
数据手册 |
MOC301 | 6-DIP (0.300", 7.62mm) | Tube | Active | Triac | No | 1 | 5300Vrms | 250 V | 10V/µs (Typ) | 5mA | - | 100µA (Typ) | - | 1.2V | 50 mA | -40°C ~ 100°C | Through Hole | 6-DIP | UL, VDE |
|
|
MOC30226PIN RANDOM PHASE TRIAC, OPTOCOU |
1,495 |
|
数据手册 |
MOC302 | 6-DIP (0.300", 7.62mm) | Tube | Active | Triac | No | 1 | 5000Vrms | 400 V | 10V/µs (Typ) | 10mA | - | 100µA | - | 1.2V | 50 mA | -40°C ~ 100°C | Through Hole | 6-DIP | UL, VDE |
|
|
MOC30216PIN RANDOM PHASE TRIAC, OPTOCOU |
2,798 |
|
数据手册 |
MOC302 | 6-DIP (0.300", 7.62mm) | Tube | Active | Triac | No | 1 | 5000Vrms | 400 V | 10V/µs (Typ) | 15mA | - | 100µA | - | 1.2V | 50 mA | -40°C ~ 100°C | Through Hole | 6-DIP | UL, VDE |
|
|
H11J26PIN RANDOM PHASE TRIAC, OPTOCOU |
4,507 |
|
数据手册 |
H11J | 6-DIP (0.300", 7.62mm) | Tube | Active | Triac | No | 1 | 5300Vrms | 250 V | 10V/µs (Typ) | 15mA | - | 100µA | - | 1.2V | 50 mA | -40°C ~ 100°C | Through Hole | 6-DIP | UL, VDE |
|
|
MF30324PIN ZERO CROSSING TRIAC, SMD, S |
1,139 |
|
数据手册 |
MF303x | 4-SMD, Gull Wing | Tape & Reel (TR) | Active | Triac | Yes | 1 | 3750Vrms | 250 V | 1kV/µs | 10mA | - | 280µA | - | 1.5V (Max) | 60 mA | -40°C ~ 110°C | Surface Mount | - | UL |
|
|
MF30414PIN ZERO CROSSING TRIAC, SMD, S |
3,178 |
|
数据手册 |
MF304x | 4-SMD, Gull Wing | Tape & Reel (TR) | Active | Triac | Yes | 1 | 3750Vrms | 400 V | 1kV/µs | 15mA | - | 280µA | - | 1.5V (Max) | 60 mA | -40°C ~ 110°C | Surface Mount | - | UL |
|
|
MF30604PIN ZERO CROSSING TRIAC, SMD, S |
3,472 |
|
数据手册 |
MF306x | 4-SMD, Gull Wing | Tape & Reel (TR) | Active | Triac | Yes | 1 | 3750Vrms | 600 V | 1kV/µs | 30mA | - | 280µA | - | 1.5V (Max) | 60 mA | -40°C ~ 110°C | Surface Mount | - | UL |
|
|
MF30434PIN ZERO CROSSING TRIAC, SMD, S |
2,825 |
|
数据手册 |
MF304x | 4-SMD, Gull Wing | Tape & Reel (TR) | Active | Triac | Yes | 1 | 3750Vrms | 400 V | 1kV/µs | 5mA | - | 280µA | - | 1.5V (Max) | 60 mA | -40°C ~ 110°C | Surface Mount | - | UL |
|
|
MF30404PIN ZERO CROSSING TRIAC, SMD, S |
2,710 |
|
数据手册 |
MF304x | 4-SMD, Gull Wing | Tape & Reel (TR) | Active | Triac | Yes | 1 | 3750Vrms | 400 V | 1kV/µs | 30mA | - | 280µA | - | 1.5V (Max) | 60 mA | -40°C ~ 110°C | Surface Mount | - | UL |
|
|
MF30334PIN ZERO CROSSING TRIAC, SMD, S |
4,077 |
|
数据手册 |
MF303x | 4-SMD, Gull Wing | Tape & Reel (TR) | Active | Triac | Yes | 1 | 3750Vrms | 250 V | 1kV/µs | 5mA | - | 280µA | - | 1.5V (Max) | 60 mA | -40°C ~ 110°C | Surface Mount | - | UL |
|
|
MF30424PIN ZERO CROSSING TRIAC, SMD, S |
3,255 |
|
数据手册 |
MF304x | 4-SMD, Gull Wing | Tape & Reel (TR) | Active | Triac | Yes | 1 | 3750Vrms | 400 V | 1kV/µs | 10mA | - | 280µA | - | 1.5V (Max) | 60 mA | -40°C ~ 110°C | Surface Mount | - | UL |
|
|
MF30614PIN ZERO CROSSING TRIAC, SMD, S |
3,044 |
|
数据手册 |
MF306x | 4-SMD, Gull Wing | Tape & Reel (TR) | Active | Triac | Yes | 1 | 3750Vrms | 600 V | 1kV/µs | 15mA | - | 280µA | - | 1.5V (Max) | 60 mA | -40°C ~ 110°C | Surface Mount | - | UL |
|
|
MF30634PIN ZERO CROSSING TRIAC, SMD, S |
4,454 |
|
数据手册 |
MF306x | 4-SMD, Gull Wing | Tape & Reel (TR) | Active | Triac | Yes | 1 | 3750Vrms | 600 V | 1kV/µs | 5mA | - | 280µA | - | 1.5V (Max) | 60 mA | -40°C ~ 110°C | Surface Mount | - | UL |
