固定电感器
| 图片 | 制造商型号 | 库存情况 | 数量 | 数据手册 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CTCDRH8D43F-150N15UH SMD SHIELDED POWER INDUCTOR Central Technologies |
800 |
|
数据手册 |
CTCDRH8D43F | Nonstandard | Tape & Reel (TR) | Active | - | - | 15 µH | ±30% | - | 2.6A | Shielded | 53mOhm Max | - | - | - | -30°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.327" L x 0.327" W (8.30mm x 8.30mm) | 0.185" (4.70mm) |
|
|
CTCDRH8D43F-220N22UH SMD SHIELDED POWER INDUCTOR Central Technologies |
114 |
|
数据手册 |
CTCDRH8D43F | Nonstandard | Tape & Reel (TR) | Active | - | - | 22 µH | ±30% | - | 2.1A | Shielded | 75mOhm Max | - | - | - | -30°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.327" L x 0.327" W (8.30mm x 8.30mm) | 0.185" (4.70mm) |
|
CTSLF0628TF-220M22UH SMD SHLDED POWER INDUCTOR Central Technologies |
109 |
|
数据手册 |
CTSLF0628TF | Nonstandard | Tape & Reel (TR) | Active | - | - | 22 µH | ±20% | 1.3 A | 770mA | Shielded | 104mOhm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.236" L x 0.236" W (6.00mm x 6.00mm) | 0.118" (3.00mm) |
|
CTCDRH8D28F-7R3N7.3UH SMD SHIELDED POWR INDUCTOR Central Technologies |
1,000 |
|
数据手册 |
CTCDRH8D28F | Nonstandard | Tape & Reel (TR) | Active | - | - | 7.3 µH | ±30% | - | 2.8A | Shielded | 38mOhm Max | - | - | - | -30°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.327" L x 0.327" W (8.30mm x 8.30mm) | 0.118" (3.00mm) |
|
|
CTCDRH8D28F-100N10UH SMD SHIELDED POWER INDUCTOR Central Technologies |
1,000 |
|
数据手册 |
CTCDRH8D28F | Nonstandard | Tape & Reel (TR) | Active | - | - | 10 µH | ±30% | - | 2.3A | Shielded | 42mOhm Max | - | - | - | -30°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.327" L x 0.327" W (8.30mm x 8.30mm) | 0.118" (3.00mm) |
|
|
CTCDRH8D28F-220N22UH SMD SHIELDED POWER INDUCTOR Central Technologies |
1,000 |
|
数据手册 |
CTCDRH8D28F | Nonstandard | Tape & Reel (TR) | Active | - | - | 22 µH | ±30% | - | 1.6A | Shielded | 95mOhm Max | - | - | - | -30°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.327" L x 0.327" W (8.30mm x 8.30mm) | 0.118" (3.00mm) |
|
CTH6EF-1R5K1.5UH MINI AXL P-LINE INDUCTOR Central Technologies |
5,996 |
|
数据手册 |
CTH6F | Axial | Tape & Reel (TR) | Active | Wirewound | - | 1.5 µH | ±10% | 3.1 A | 2.5A | Unshielded | 20mOhm Max | - | 160MHz | - | -55°C ~ 105°C | 7.9 MHz | - | Through Hole | Axial | 0.160" Dia x 0.500" L (4.06mm x 12.70mm) | - |
|
|
CTH6EF-1R8K1.8UH MINI AXL P-LINE INDUCTOR Central Technologies |
5,650 |
|
数据手册 |
CTH6F | Axial | Tape & Reel (TR) | Active | Wirewound | - | 1.8 µH | ±10% | 2.9 A | 2.1A | Unshielded | 20mOhm Max | - | 150MHz | - | -55°C ~ 105°C | 7.9 MHz | - | Through Hole | Axial | 0.160" Dia x 0.500" L (4.06mm x 12.70mm) | - |
|
CTSLF0732TF-3R3M3.3UH SMD SHLDED POWER INDUCTOR Central Technologies |
2,000 |
|
数据手册 |
CTSLF0732TF | Nonstandard | Tape & Reel (TR) | Active | - | - | 3.3 µH | ±20% | 1.9 A | - | Shielded | 23mOhm | - | - | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.276" L x 0.276" W (7.00mm x 7.00mm) | 0.134" (3.40mm) |
|
|
CTH6EF-680K68UH MINI AXL P-LINE INDUCTOR Central Technologies |
1,700 |
|
数据手册 |
CTH6F | Axial | Tape & Reel (TR) | Active | Wirewound | - | 68 µH | ±10% | 610 mA | 370mA | Unshielded | 530mOhm Max | - | 4.3MHz | - | -55°C ~ 105°C | 1 kHz | - | Through Hole | Axial | 0.160" Dia x 0.500" L (4.06mm x 12.70mm) | - |
