固定电感器
| 图片 | 制造商型号 | 库存情况 | 数量 | 数据手册 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CT132SMF-09TJSMD AIR CORE INDUCTOR Central Technologies |
1,005 |
|
数据手册 |
ct132smf | - | Tape & Reel (TR) | Active | Wirewound | - | 90 nH | ±5% | - | - | - | 8.2Ohm | - | 1GHz | - | -40°C ~ 85°C | - | - | Surface Mount | - | - | - |
|
|
CT132SMF-13TJSMD AIR CORE INDUCTOR Central Technologies |
1,005 |
|
数据手册 |
ct132smf | - | Tape & Reel (TR) | Active | Wirewound | - | 206 nH | ±5% | - | - | - | 10.1Ohm | - | 700MHz | - | -40°C ~ 85°C | - | - | Surface Mount | - | - | - |
|
CTGS73F-220M22UH SMD UNSHLD POWER INDUCTOR Central Technologies |
1,000 |
|
数据手册 |
CTGS73F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 22 µH | ±20% | 1.07 A | - | Unshielded | 130mOhm Max | - | - | - | -30°C ~ 100°C | 2.52 MHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.150" (3.80mm) |
|
CTCDRH127/LDF-7R4N7.4UH SMD SHIELDED POWR INDUCTOR Central Technologies |
500 |
|
数据手册 |
CTCDRH127/LDF | Nonstandard | Tape & Reel (TR) | Active | - | - | 7.4 µH | ±30% | 6.9 A | 7.4A | Shielded | 17.7mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.492" L x 0.492" W (12.50mm x 12.50mm) | 0.315" (8.00mm) |
|
CTC0F-1R0JAXL LEADED CONF COATED INDUCTOR Central Technologies |
500 |
|
数据手册 |
ctc0f | - | Tape & Reel (TR) | Active | - | - | 1 µH | ±5% | - | - | - | 800mOhm | - | 150MHz | - | -55°C ~ 125°C | - | - | Through Hole | - | - | - |
|
|
CTC0F-8R2JAXL LEADED CONF COATED INDUCTOR Central Technologies |
500 |
|
数据手册 |
ctc0f | - | Tape & Reel (TR) | Active | - | - | 8.2 µH | ±5% | - | - | - | 2.2Ohm | - | 26MHz | - | -55°C ~ 125°C | - | - | Through Hole | - | - | - |
|
|
CTGS73F-151K150UH SMD UNSHLD POWER INDUCTOR Central Technologies |
500 |
|
数据手册 |
CTGS73F | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 150 µH | ±10% | 400 mA | - | Unshielded | 750mOhm Max | - | - | - | -30°C ~ 100°C | 1 kHz | - | Surface Mount | - | 0.307" L x 0.276" W (7.80mm x 7.00mm) | 0.150" (3.80mm) |
|
|
CTCDRH127/LDF-150M15UH SMD SHIELDED POWR INDUCTOR Central Technologies |
500 |
|
数据手册 |
CTCDRH127/LDF | Nonstandard | Tape & Reel (TR) | Active | - | - | 15 µH | ±20% | 5.31 A | 5.65A | Shielded | 26.4mOhm Max | - | - | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.492" L x 0.492" W (12.50mm x 12.50mm) | 0.315" (8.00mm) |
|
|
CTCDRH127/LDF-100M10UH SMD SHIELDED POWR INDUCTOR Central Technologies |
390 |
|
数据手册 |
CTCDRH127/LDF | Nonstandard | Tape & Reel (TR) | Active | - | - | 10 µH | ±20% | 6.21 A | 6.7A | Shielded | 19.5mOhm Max | - | - | - | -40°C ~ 125°C | 1 kHz | - | Surface Mount | - | 0.492" L x 0.492" W (12.50mm x 12.50mm) | 0.315" (8.00mm) |
|
|
CT132SMF-19TJSMD AIR CORE INDUCTOR Central Technologies |
200 |
|
数据手册 |
ct132smf | - | Tape & Reel (TR) | Active | Wirewound | - | 491 nH | ±5% | - | - | - | 39.4Ohm | - | 400MHz | - | -40°C ~ 85°C | - | - | Surface Mount | - | - | - |
