直流无刷风扇（BLDC）
| 图片 | 制造商型号 | 库存情况 | 数量 | 数据手册 | 系列 | 包装 | 产品状态 | 额定电压 | 尺寸 / 尺寸 | 宽度 | 气流 | 静压 | 轴承类型 | 风扇类型 | 特性 | 噪音 | 功率（瓦特） | 转速（RPM） | 端接方式 | 防护等级 | 工作温度 | 认证机构 | 重量 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CFM-5010B-155-313-20DC AXIAL FAN, 50 MM SQUARE, 10 M Same Sky (Formerly CUI Devices) |
3,403 |
|
数据手册 |
CFM-50B | Box | Active | 12VDC | Square - 50mm L x 50mm H | 10.50mm | 11.8 CFM (0.330m³/min) | 0.130 in H2O (32.4 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 31.3dB(A) | 1.56 W | 5500 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CFM-6020B-130-257FAN AXIAL 60X20MM 12VDC WIRE Same Sky (Formerly CUI Devices) |
4,714 |
|
数据手册 |
CFM-60B | Box | Active | 12VDC | Square - 60mm L x 60mm H | 20.00mm | 11.4 CFM (0.319m³/min) | 0.060 in H2O (14.9 Pa) | Ball | Tubeaxial | Auto Restart | 25.7dB(A) | 960 mW | 3000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CFM-5015BF-175-423FAN AXIAL 50X15.5MM 12VDC WIRE Same Sky (Formerly CUI Devices) |
4,362 |
|
数据手册 |
CFM-50BF | Box | Active | 12VDC | Square - 50mm L x 50mm H | 15.50mm | 19.5 CFM (0.546m³/min) | 0.320 in H2O (79.7 Pa) | Ball | Tubeaxial | Auto Restart | 42.3dB(A) | 3.84 W | 7500 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CFM-6020S-150-368-22FAN AXIAL 60X20MM 12VDC WIRE Same Sky (Formerly CUI Devices) |
2,666 |
|
数据手册 |
CFM-60S | Box | Active | 12VDC | Square - 60mm L x 60mm H | 20.00mm | 19.1 CFM (0.535m³/min) | 0.180 in H2O (45.0 Pa) | Sleeve | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 36.8dB(A) | 2.52 W | 5000 RPM | 4 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
CFM-5020B-245-306DC AXIAL FAN, 50 MM SQUARE, 20 M Same Sky (Formerly CUI Devices) |
3,247 |
|
数据手册 |
CFM-50B | Box | Active | 24VDC | Square - 50mm L x 50mm H | 19.80mm | 13.6 CFM (0.381m³/min) | 0.140 in H2O (34.9 Pa) | Ball | Tubeaxial | Auto Restart | 30.6dB(A) | 0.96 W | 4500 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CFM-4010B-265-251-20FAN AXIAL 40X10.5MM 24VDC WIRE Same Sky (Formerly CUI Devices) |
3,238 |
|
数据手册 |
CFM-40B | Box | Active | 24VDC | Square - 40mm L x 40mm H | 10.50mm | 5.5 CFM (0.154m³/min) | 0.110 in H2O (27.4 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 25.1dB(A) | 1.44 W | 6500 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CFM-2510B-1130-275-20FAN AXIAL 25X10MM 12VDC WIRE Same Sky (Formerly CUI Devices) |
1,449 |
|
数据手册 |
CFM-25B | Box | Active | 12VDC | Square - 25mm L x 25mm H | 10.00mm | 2.5 CFM (0.070m³/min) | 0.220 in H2O (54.8 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 27.5dB(A) | 1.32 W | 13000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
CBM-5015BF-045-348-22DC BLOWER, 51.7 X 51.25 X 14.9 M Same Sky (Formerly CUI Devices) |
4,532 |
|
数据手册 |
CBM-50BF | Box | Active | 5VDC | Rectangular/Rounded - 51.6mm L x 51.2mm H | 15.00mm | 2.9 CFM (0.081m³/min) | 0.450 in H2O (112.1 Pa) | Ball | Blower | PWM Control, Speed Sensor (Tach) | 34.8dB(A) | 1.05 W | 4500 RPM | 4 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
CBM-5015BF-035-293-22DC BLOWER, 51.7 X 51.25 X 14.9 M Same Sky (Formerly CUI Devices) |
1,314 |
|
数据手册 |
CBM-50BF | Box | Active | 5VDC | Rectangular/Rounded - 51.6mm L x 51.2mm H | 15.00mm | 2.2 CFM (0.061m³/min) | 0.270 in H2O (67.3 Pa) | Ball | Blower | PWM Control, Speed Sensor (Tach) | 29.3dB(A) | 700 mW | 3500 RPM | 4 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CFM-6010-13-11FAN AXIAL 60X10.6MM 12VDC WIRE Same Sky (Formerly CUI Devices) |
4,110 |
|
数据手册 |
CFM-60 | Tray | Obsolete | 12VDC | Square - 60mm L x 60mm H | 10.60mm | 24.2 CFM (0.678m³/min) | 0.220 in H2O (54.8 Pa) | Ball | Tubeaxial | Auto Restart, Locked Rotor Sensor | 41.4dB(A) | 3.12 W | 5500 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | 0.064 lb (29.03 g) |
