汽车继电器
| 图片 | 制造商型号 | 库存情况 | 数量 | 数据手册 | 系列 | 包装 | 产品状态 | 线圈类型 | 线圈电流 | 线圈电压 | 触点形式 | 触点额定值（电流） | 切换电压 | 必须动作电压 | 必须释放电压 | 动作时间 | 释放时间 | 特性 | 安装类型 | 端接样式 | 工作温度 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PC792C-1A-C1-12C-RN-XRELAY AUTOMOTIVE SPST 50A 12V Picker Components |
1,977 |
|
数据手册 |
- | Box | Active | Non Latching | 168 mA | 12VDC | SPST-NO (1 Form A) | - | 75VDC - Max | 7.8 VDC | 1.2 VDC | 7 ms | 2 ms | Resistor | Chassis Mount | Quick Connect - 0.250" (6.3mm) | -40°C ~ 125°C |
|
PC792C-1A-C-12C-RN-XRELAY AUTOMOTIVE SPST 50A 12V Picker Components |
4,417 |
|
数据手册 |
- | Box | Active | Non Latching | 168 mA | 12VDC | SPST-NO (1 Form A) | - | 75VDC - Max | 7.8 VDC | 1.2 VDC | 7 ms | 2 ms | Resistor | Socketable | Plug In, Quick Connect - 0.250" (6.3mm) | -40°C ~ 125°C |
|
PC792E-1C-C-12C-RN-XRELAY AUTOMOTIVE SPDT 50A 12V Picker Components |
3,153 |
|
数据手册 |
- | Box | Active | Non Latching | 150.9 mA | 12VDC | SPDT (1 Form C) | - | 75VDC - Max | 7.8 VDC | 1.8 VDC | 7 ms | 5 ms | Resistor | Socketable | Plug In, Quick Connect - 0.250" (6.3mm) | -40°C ~ 125°C |
|
PC792B-1C-P-12S-D-XRELAY AUTOMOTIVE SPDT 40A 12V Picker Components |
1,613 |
|
数据手册 |
- | Bag | Active | Non Latching | 133.3 mA | 12VDC | SPDT (1 Form C) | - | 75VDC - Max | 7.8 VDC | 1.8 VDC | 7 ms | 2 ms | Diode, Sealed - Fully | Through Hole | PC Pin | -40°C ~ 125°C |
|
PC795-1A-C2-12C-RN-XRELAY AUTOMOTIVE SPST 80A 12V Picker Components |
3,875 |
|
数据手册 |
- | Box | Active | Non Latching | 168 mA | 12VDC | SPST-NO (1 Form A) | - | 75VDC - Max | 7.8 VDC | 1.2 VDC | 7 ms | 2 ms | Resistor | Chassis Mount | Quick Connect - 0.250" (6.3mm) | -40°C ~ 125°C |
|
PC793-1A-P-12S-XRELAY AUTOMOTIVE SPST 70A 12V Picker Components |
2,441 |
|
数据手册 |
- | Tray | Active | Non Latching | 133 mA | 12VDC | SPST-NO (1 Form A) | - | 120VDC - Max | 7.8 VDC | 1.2 VDC | 10 ms | 10 ms | Sealed - Fully | Through Hole | PC Pin | -40°C ~ 125°C |
|
PC793-1A-C1-12S-N-XRELAY AUTOMOTIVE SPST 70A 12V Picker Components |
1,562 |
|
数据手册 |
- | Tray | Active | Non Latching | 133 mA | 12VDC | SPST-NO (1 Form A) | - | 120VDC - Max | 7.8 VDC | 1.2 VDC | 10 ms | 10 ms | Sealed - Fully | Chassis Mount | Quick Connect - 0.250" (6.3mm) | -40°C ~ 125°C |
|
PC793-1A-C-12S1-RN-XRELAY AUTOMOTIVE SPST 70A 12V Picker Components |
2,722 |
|
数据手册 |
- | Tray | Active | Non Latching | 150 mA | 12VDC | SPST-NO (1 Form A) | - | 120VDC - Max | 7.8 VDC | 1.2 VDC | 10 ms | 10 ms | Resistor, Sealed - Flux Protection | Socketable | Plug In, Quick Connect - 0.250" (6.3mm) | -40°C ~ 125°C |
|
PC793-1A-C2-12S-RN-XRELAY AUTOMOTIVE SPST 70A 12V Picker Components |
4,666 |
|
数据手册 |
- | Tray | Active | Non Latching | 150 mA | 12VDC | SPST-NO (1 Form A) | - | 120VDC - Max | 7.8 VDC | 1.2 VDC | 10 ms | 10 ms | Resistor, Sealed - Fully | Chassis Mount | Quick Connect - 0.250" (6.3mm) | -40°C ~ 125°C |
|
PC795-1C-C2-24S-N-XRELAY AUTOMOTIVE SPDT 40A 24V Picker Components |
2,452 |
|
数据手册 |
- | Bag | Active | Non Latching | 75 mA | 24VDC | SPDT (1 Form C) | - | 75VDC - Max | 15.6 VDC | 2.4 VDC | 7 ms | 2 ms | Sealed - Fully | Chassis Mount | Quick Connect - Multiple Sizes | -40°C ~ 125°C |
