散热器
| 图片 | 制造商型号 | 库存情况 | 数量 | 数据手册 | 系列 | 包装 | 产品状态 | 类型 | 冷却封装 | 附件方式 | 形状 | 长度 | 宽度 | 直径 | Fin 高度 | 功耗 @ 温升 | 热阻 @ 强制气流 | 热阻 @ 自然对流 | 材质 | 材料表面处理 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
513201B02500GHEATSINK TO-218/TO-247 W/PINS 2" Boyd Laconia, LLC |
1,697 |
|
数据手册 |
- | Bulk | Active | Board Level, Vertical | TO-218 | Bolt On and PC Pin | Rectangular, Fins | 2.000" (50.80mm) | 1.375" (34.93mm) | - | 0.500" (12.70mm) | 2.0W @ 20°C | 3.00°C/W @ 400 LFM | 8.30°C/W | Aluminum | Black Anodized |
|
6025DGHEATSINK TO-220 STAGGEREDFIN TIN Boyd Laconia, LLC |
8,081 |
|
数据手册 |
- | Bulk | Active | Board Level, Vertical | TO-220 | Bolt On and PC Pin | Rectangular, Fins | 1.250" (31.75mm) | 0.875" (22.23mm) | - | 0.250" (6.35mm) | 3.0W @ 60°C | 7.00°C/W @ 400 LFM | 17.90°C/W | Copper | Tin |
|
375424B00034GHEATSINK PIN-FIN W/TAPE Boyd Laconia, LLC |
2,277 |
|
数据手册 |
- | Bulk | Active | Top Mount | BGA | Thermal Tape, Adhesive (Included) | Square, Pin Fins | 0.598" (15.19mm) | 0.598" (15.19mm) | - | 0.252" (6.40mm) | - | 17.60°C/W @ 200 LFM | 62.50°C/W | Aluminum | Black Anodized |
|
374024B00035GHEATSINK BGA 23X23X10MM W/ADH Boyd Laconia, LLC |
1,892 |
|
数据手册 |
- | Bulk | Active | Top Mount | BGA | Thermal Tape, Adhesive (Included) | Square, Pin Fins | 0.906" (23.01mm) | 0.906" (23.01mm) | - | 0.394" (10.00mm) | 1.0W @ 40°C | 11.70°C/W @ 200 LFM | 40.00°C/W | Aluminum | Black Anodized |
|
529702B02500GBOARD LEVEL HEATSINK 1" TO-220 Boyd Laconia, LLC |
2,157 |
|
数据手册 |
- | Bulk | Active | Board Level, Vertical | TO-220 | Bolt On and PC Pin | Rectangular, Fins | 1.000" (25.40mm) | 1.650" (41.91mm) | - | 1.000" (25.40mm) | 4.0W @ 30°C | 4.00°C/W @ 200 LFM | 5.50°C/W | Aluminum | Black Anodized |
|
7109D/TRGHEATSINK TO-263 (D2PK) Boyd Laconia, LLC |
9,031 |
|
数据手册 |
- | Tape & Reel (TR) | Active | Top Mount | TO-263 (D²Pak) | SMD Pad | Rectangular, Fins | 0.763" (19.38mm) | 1.000" (25.40mm) | - | 0.450" (11.43mm) | 2.0W @ 30°C | 3.00°C/W @ 300 LFM | 11.00°C/W | Copper | Tin |
|
575200B00000GHEATSINK TO-92 .72" BLK Boyd Laconia, LLC |
2,993 |
|
数据手册 |
- | Bag | Active | Board Level, Vertical | TO-92 | Press Fit | Rectangular, Fins | 0.602" (15.29mm) | - | - | 0.720" (18.29mm) | 0.3W @ 20°C | 17.50°C/W @ 400 LFM | 60.00°C/W | Aluminum | Black Anodized |
|
574402B03200GHEATSINK TO220 HOR MNT W/TAB.75" Boyd Laconia, LLC |
3,374 |
|
数据手册 |
- | Bulk | Active | Board Level | TO-220 | Clip and PC Pin | Rectangular, Fins | 0.750" (19.05mm) | 0.860" (21.84mm) | - | 0.395" (10.03mm) | 3.0W @ 60°C | 12.00°C/W @ 200 LFM | 23.20°C/W | Aluminum | Black Anodized |
|
531102B02500GHEATSINK TO-220 W/PINS 1.5"TALL Boyd Laconia, LLC |
1,329 |
|
数据手册 |
- | Bulk | Active | Board Level, Vertical | TO-220 | Bolt On and PC Pin | Rectangular, Fins | 1.500" (38.10mm) | 1.375" (34.93mm) | - | 0.500" (12.70mm) | 7.0W @ 70°C | 3.00°C/W @ 500 LFM | 10.40°C/W | Aluminum | Black Anodized |
|
529901B02500GHEATSINK TO-218 SOLDER PIN Boyd Laconia, LLC |
225 |
|
数据手册 |
- | Bulk | Active | Board Level, Vertical | TO-218 | Bolt On and PC Pin | Rectangular, Fins | 2.000" (50.80mm) | 1.650" (41.91mm) | - | 1.000" (25.40mm) | 12.0W @ 50°C | 1.00°C/W @ 800 LFM | 4.50°C/W | Aluminum | Black Anodized |
