钽 - 聚合物电容器
| 图片 | 制造商型号 | 库存情况 | 数量 | 数据手册 | 系列 | 封装/外壳 | 包装 | 产品状态 | 电容 | 容差 | 额定电压 | 类型 | ESR（等效串联电阻） | 工作温度 | 寿命 @ 温度 | 安装类型 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） | 引线间距 | 制造商尺寸代码 | 额定值 | 特性 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
T543D157K010AHW005D100CAP TANT POLY 150UF 10V 2917 |
8,262 |
|
数据手册 |
KO-CAP® T543 | 2917 (7343 Metric) | Tape & Reel (TR) | Active | 150 µF | ±10% | 10 V | Molded | 5mOhm @ 100kHz | -55°C ~ 105°C | 2000 Hrs @ 105°C | Surface Mount | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.122" (3.10mm) | - | D | COTS | High Reliability |
|
T555B826K075AHCAP TANT POLY 82UF 75V SMD |
6,907 |
|
数据手册 |
T555 | Nonstandard | Box | Active | 82 µF | ±10% | 75 V | Hermetically Sealed | 220mOhm @ 100kHz | -55°C ~ 105°C | 2000 Hrs @ 105°C | Surface Mount | 0.965" L x 0.335" W (24.50mm x 8.50mm) | 0.378" (9.60mm) | - | B | - | General Purpose |
|
T54E6137M075VSB017CAP TANT POLY 130UF 75V SMD |
7,749 |
|
数据手册 |
vPolyTan™ T54 | Nonstandard | Tray | Active | 130 µF | ±20% | 75 V | Molded | 17mOhm @ 100kHz | -55°C ~ 125°C | 2000 Hrs @ 125°C | Surface Mount | 0.315" L x 0.350" W (8.00mm x 8.90mm) | 0.539" (13.68mm) | - | E6 | COTS | High Reliability |
|
T599B336M010ATE070CAP TANT POLY 33UF 10V 1411 |
8,027 |
|
数据手册 |
KO-CAP® T599 | 1411 (3528 Metric) | Tape & Reel (TR) | Active | 33 µF | ±20% | 10 V | Molded | 70mOhm @ 100kHz | -55°C ~ 150°C | 2000 Hrs @ 150°C | Surface Mount | 0.138" L x 0.110" W (3.50mm x 2.80mm) | 0.083" (2.10mm) | - | B | AEC-Q200 | Automotive |
|
T55A156M6R3C0500CAP TANT POLY 15UF 6.3V 1206 |
6,885 |
|
数据手册 |
vPolyTan™ T55 | 1206 (3216 Metric) | Tape & Reel (TR) | Active | 15 µF | ±20% | 6.3 V | Molded | 500mOhm @ 100kHz | -55°C ~ 105°C | - | Surface Mount | 0.126" L x 0.063" W (3.20mm x 1.60mm) | 0.071" (1.80mm) | - | A | - | General Purpose |
|
|
T55A156M6R3C0200CAP TANT POLY 15UF 6.3V 1206 |
8,346 |
|
数据手册 |
vPolyTan™ T55 | 1206 (3216 Metric) | Tape & Reel (TR) | Active | 15 µF | ±20% | 6.3 V | Molded | 200mOhm @ 100kHz | -55°C ~ 105°C | - | Surface Mount | 0.126" L x 0.063" W (3.20mm x 1.60mm) | 0.071" (1.80mm) | - | A | - | General Purpose |
|
|
T55A686M004C0500CAP TANT POLY 68UF 4V 1206 |
3,073 |
|
数据手册 |
vPolyTan™ T55 | 1206 (3216 Metric) | Tape & Reel (TR) | Active | 68 µF | ±20% | 4 V | Molded | 500mOhm @ 100kHz | -55°C ~ 105°C | - | Surface Mount | 0.126" L x 0.063" W (3.20mm x 1.60mm) | 0.071" (1.80mm) | - | A | - | General Purpose |
.JPG)
|
T55B227M004C0070CAP TANT POLY 220UF 4V 1411 |
4,531 |
|
数据手册 |
vPolyTan™ T55 | 1411 (3528 Metric) | Tape & Reel (TR) | Active | 220 µF | ±20% | 4 V | Molded | 70mOhm @ 100kHz | -55°C ~ 105°C | - | Surface Mount | 0.138" L x 0.110" W (3.50mm x 2.80mm) | 0.083" (2.10mm) | - | B | - | General Purpose |
|
|
T55B476M6R3C0070CAP TANT POLY 47UF 6.3V 1411 |
4,331 |
|
数据手册 |
vPolyTan™ T55 | 1411 (3528 Metric) | Tape & Reel (TR) | Active | 47 µF | ±20% | 6.3 V | Molded | 70mOhm @ 100kHz | -55°C ~ 105°C | - | Surface Mount | 0.138" L x 0.110" W (3.50mm x 2.80mm) | 0.083" (2.10mm) | - | B | - | General Purpose |
A.JPG)
|
T520A476M2R5ATE090CAP TANT POLY 47UF 2.5V 1206 |
2,435 |
|
数据手册 |
KO-CAP® T520 | 1206 (3216 Metric) | Tape & Reel (TR) | Active | 47 µF | ±20% | 2.5 V | Molded | 90mOhm @ 100kHz | -55°C ~ 105°C | 2000 Hrs @ 105°C | Surface Mount | 0.126" L x 0.063" W (3.20mm x 1.60mm) | 0.071" (1.80mm) | - | A | - | General Purpose |
|
|
T55B107M6R3C0045CAP TANT POLY 100UF 6.3V 1411 |
5,183 |
|
数据手册 |
vPolyTan™ T55 | 1411 (3528 Metric) | Tape & Reel (TR) | Active | 100 µF | ±20% | 6.3 V | Molded | 45mOhm @ 100kHz | -55°C ~ 105°C | - | Surface Mount | 0.138" L x 0.110" W (3.50mm x 2.80mm) | 0.083" (2.10mm) | - | B | - | General Purpose |
|
TCJB106M025R0150ECAP TANT POLY 10UF 25V 1210 |
8,612 |
|
数据手册 |
TCJ | 1210 (3528 Metric) | Tape & Reel (TR) | Active | 10 µF | ±20% | 25 V | Molded | 150mOhm @ 100kHz | -55°C ~ 105°C | 2000 Hrs @ 105°C | Surface Mount | 0.138" L x 0.110" W (3.50mm x 2.80mm) | 0.083" (2.10mm) | - | B | - | General Purpose |
|
T597S336M006APE200CAP TANT POLY 33UF 6.3V 1206 |
9,509 |
|
数据手册 |
KO-CAP® T597 | 1206 (3216 Metric) | Tape & Reel (TR) | Active | 33 µF | ±20% | 6.3 V | Molded | 200mOhm @ 100kHz | -55°C ~ 125°C | 2000 Hrs @ 125°C | Surface Mount | 0.126" L x 0.063" W (3.20mm x 1.60mm) | 0.047" (1.20mm) | - | - | AEC-Q200 | Automotive |
|
T591B686M006ATE070CAP TANT POLY 68UF 6.3V 1411 |
3,711 |
|
数据手册 |
KO-CAP® T591 | 1411 (3528 Metric) | Tape & Reel (TR) | Active | 68 µF | ±20% | 6.3 V | Molded | 70mOhm @ 100kHz | -55°C ~ 125°C | 1000 Hrs @ 125°C | Surface Mount | 0.138" L x 0.110" W (3.50mm x 2.80mm) | 0.083" (2.10mm) | - | B | - | General Purpose |
|
T527I336M010ATE200CAP TANT POLY 33UF 10V 1206 |
4,030 |
|
数据手册 |
KO-CAP® T527 | 1206 (3216 Metric) | Tape & Reel (TR) | Active | 33 µF | ±20% | 10 V | Molded | 200mOhm @ 100kHz | -55°C ~ 105°C | - | Surface Mount | 0.126" L x 0.063" W (3.20mm x 1.60mm) | 0.039" (1.00mm) | - | I | - | General Purpose |
|
|
TCJH157M006R0200ECAP TANT POLY 150UF 6.3V 1210 |
7,017 |
|
数据手册 |
TCJ | 1210 (3528 Metric) | Tape & Reel (TR) | Active | 150 µF | ±20% | 6.3 V | Molded | 200mOhm @ 100kHz | -55°C ~ 105°C | 2000 Hrs @ 105°C | Surface Mount | 0.138" L x 0.110" W (3.50mm x 2.80mm) | 0.059" (1.50mm) | - | H | - | General Purpose |
|
|
TCJA336M006R0200ECAP TANT POLY 33UF 6.3V 1206 |
4,994 |
|
数据手册 |
TCJ | 1206 (3216 Metric) | Tape & Reel (TR) | Active | 33 µF | ±20% | 6.3 V | Molded | 200mOhm @ 100kHz | -55°C ~ 105°C | 2000 Hrs @ 105°C | Surface Mount | 0.126" L x 0.063" W (3.20mm x 1.60mm) | 0.071" (1.80mm) | - | A | - | General Purpose |
|
|
TCJB155M035R0200CAP TANT POLY 1.5UF 35V 1210 |
9,922 |
|
数据手册 |
TCJ | 1210 (3528 Metric) | Tape & Reel (TR) | Active | 1.5 µF | ±20% | 35 V | Molded | 200mOhm @ 100kHz | -55°C ~ 105°C | 2000 Hrs @ 105°C | Surface Mount | 0.138" L x 0.110" W (3.50mm x 2.80mm) | 0.083" (2.10mm) | - | B | - | General Purpose |
|
|
T55B685M035C0200CAP TANT POLY 6.8UF 35V 1411 |
3,193 |
|
数据手册 |
vPolyTan™ T55 | 1411 (3528 Metric) | Tape & Reel (TR) | Active | 6.8 µF | ±20% | 35 V | Molded | 200mOhm @ 100kHz | -55°C ~ 105°C | - | Surface Mount | 0.138" L x 0.110" W (3.50mm x 2.80mm) | 0.083" (2.10mm) | - | B | - | General Purpose |
|
2R5TPE220MICAP TANT POLY 220UF 2.5V 2917 |
3,779 |
|
数据手册 |
POSCAP™ TPE | 2917 (7343 Metric) | Tape & Reel (TR) | Active | 220 µF | ±20% | 2.5 V | Molded | 18mOhm @ 100kHz | -55°C ~ 105°C | 2000 Hrs @ 105°C | Surface Mount | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.079" (2.00mm) | - | D2E | - | General Purpose |
