模拟开关、复用器、解复用器
| 图片 | 制造商型号 | 库存情况 | 数量 | 数据手册 | 系列 | 包装 | 产品状态 | 开关电路 | 多路复用器/解复用器电路 | 电路数量 | 导通状态电阻（最大） | 通道与通道匹配（ΔRon） | 电压 - 供应，单（V+） | 电压 - 供应，双（V±） | 开关时间（Ton, Toff）（最大） | -3db 带宽 | 电荷注入 | 通道电容（CS(off), CD(off)） | 漏电流（IS(off)）（最大） | 串扰 | 工作温度 | 等级 | 认证 | 安装类型 | 供应商设备封装 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DG211CJIC SWITCH SPST-NCX4 175OHM 16DIP |
3,308 |
|
数据手册 |
- | Tube | Obsolete | SPST - NC | 1:1 | 4 | 175Ohm | - | - | ±4.5V ~ 18V | 1µs, 500ns | - | - | 5pF, 5pF | 5nA | -90dB @ 100kHz | 0°C ~ 70°C (TA) | - | - | Through Hole | 16-PDIP |
|
ADG736BRM-REEL7IC SWITCH SPDT X 2 4OHM 10MSOP |
1,633 |
|
数据手册 |
- | Tape & Reel (TR) | Obsolete | SPDT | 2:1 | 2 | 4Ohm | 100mOhm | 1.8V ~ 5.5V | - | 12ns, 5ns (Typ) | 200MHz | - | 9pF | 10pA (Typ) | -82dB @ 1MHz | -40°C ~ 125°C (TA) | - | - | Surface Mount | 10-MSOP |
|
QS3B491TFQS3B491 - CROSSBAR SWITCH |
161 |
|
数据手册 |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
ADG202AKP-REELIC SWITCH SPST-NCX4 90OHM 20PLCC |
1,000 |
|
数据手册 |
ADG202A | Bulk | Active | SPST - NC | 1:1 | 4 | 90Ohm | 4.5Ohm | 15V | ±15V | 300ns, 250ns | - | 20pC | 5pF, 5pF | 2nA | -80dB @ 100kHz | -40°C ~ 85°C | - | - | Surface Mount | 20-PLCC (9x9) |
|
HI9P0200-9IC SWITCH SPST-NOX2 80OHM 14SOIC |
967 |
|
数据手册 |
- | Bulk | Active | SPST - NO | 1:1 | 2 | 80Ohm | - | 15V | ±15V | 500ns, 500ns | - | - | 5.5pF, 5.5pF | 50nA | - | -40°C ~ 85°C | - | - | Surface Mount | 14-SOIC |
|
ADG793GBCPZ-500RL7IC MUX/DEMUX TRIPLE 3X1 24LFCSP |
7,000 |
|
数据手册 |
- | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Surface Mount | 24-LFCSP-VQ (4x4) |
|
MAX392CAEIC SWITCH SPST-NO X 4 35OHM |
520 |
|
数据手册 |
- | Bulk | Active | SPST - NO | 1:1 | 4 | 35Ohm | 300mOhm | 3V ~ 15V | ±3V ~ 8V | 130ns, 75ns | - | 2pC | 9pF, 9pF | 100pA | -85dB @ 1MHz | 0°C ~ 70°C (TA) | - | - | - | - |
|
ISL43L210IHZ-T7AIC SWITCH SPDTX1 360MOHM SC70-6 |
256 |
|
数据手册 |
- | Tape & Reel (TR) | Active | SPDT | 2:1 | 1 | 360mOhm (Typ) | 2mOhm | 1.1V ~ 4.5V | - | 15ns, 10ns | - | 25pC | 40pF | 30nA | -70dB @ 100kHz | -40°C ~ 85°C (TA) | - | - | Surface Mount | SC-70-6 |
|
MAX4618EPEIC SWITCH SP4T X 2 10OHM 16DIP |
1,242 |
|
数据手册 |
- | Tube | Obsolete | SP4T | 4:1 | 2 | 10Ohm | 200mOhm | 2V ~ 5.5V | - | 15ns, 10ns | - | 3pC | 5pF, 15pF | 1nA | -96dB @ 100kHz | -40°C ~ 85°C (TA) | - | - | Through Hole | 16-PDIP |
|
MAX4760AEWX+TMAX4760 HIGH-BANDWIDTH, QUAD DPD |
21,933 |
|
数据手册 |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
ADV3220ACPZ-RLIC SWITCH SPDT X 1 8LFCSP |
4,312 |
|
数据手册 |
- | Tape & Reel (TR) | Active | SPDT | 2:1 | 1 | - | - | - | ±4.5V ~ 5.5V | - | 800MHz | - | 0.6pF | 2µA (Typ) | -60dB @ 100MHz | -40°C ~ 85°C (TA) | - | - | Surface Mount | 8-LFCSP-WD (3x3) |
|
MAX4553CEE+IC SWITCH QUAD SPST 16QSOP |
4,835 |
|
数据手册 |
- | Bulk | Obsolete | SPST - NO/NC | 1:1 | 4 | 120Ohm | 1Ohm | 2V ~ 12V | ±2V ~ 6V | 110ns, 90ns | - | 2pC | 3.5pF, 3pF | 1nA | -90dB @ 100kHz | 0°C ~ 70°C (TA) | - | - | Surface Mount | 16-QSOP |
|
|
MAX4551EEEIC SW SPST-NCX4 120OHM 16QSOP |
2,239 |
|
数据手册 |
- | Tube | Obsolete | SPST - NC | 1:1 | 4 | 120Ohm | 1Ohm | 2V ~ 12V | ±2V ~ 6V | 110ns, 90ns | - | 2pC | 3.5pF, 3pF | 1nA | -90dB @ 100kHz | -40°C ~ 85°C (TA) | - | - | Surface Mount | 16-QSOP |
|
|
DG442CJIC SWITCH SPST-NOX4 85OHM 16DIP |
3,692 |
|
数据手册 |
- | Tube | Obsolete | SPST - NO | 1:1 | 4 | 85Ohm | 4Ohm (Max) | 10V ~ 30V | ±4.5V ~ 20V | 250ns, 170ns | - | 5pC | 4pF, 4pF | 500pA | -100dB @ 1MHz | 0°C ~ 70°C (TA) | - | - | Through Hole | 16-PDIP |
|
HI9P0307-5IC SWITCH DPDT X 2 50OHM 14SOIC |
358 |
|
数据手册 |
- | Bulk | Active | DPDT | 2:2 | 2 | 50Ohm | - | 44V | ±22V | 250ns, 150ns | - | 30pC | 16pF, 14pF | 5nA | - | 0°C ~ 75°C | - | - | Surface Mount | 14-SOIC |
|
ADG904BRUIC SWITCH SP4T X 1 20TSSOP |
2,742 |
|
数据手册 |
- | Tube | Obsolete | SP4T | 4:1 | 1 | - | - | 1.65V ~ 2.75V | - | 10ns, 16ns | 2.5GHz | - | 2pF | 1µA | -58dB @ 100MHz | -40°C ~ 85°C (TA) | - | - | Surface Mount | 20-TSSOP |
|
ADG201AKPIC SWITCH SPST-NCX4 90OHM 20PLCC |
1,636 |
|
数据手册 |
- | Tube | Obsolete | SPST - NC | 1:1 | 4 | 90Ohm | 4.5Ohm | 10V ~ 15V | ±10V ~ 15V | 300ns, 250ns | - | 20pC | 5pF | 2nA | -80dB @ 100kHz | -40°C ~ 85°C (TA) | - | - | Surface Mount | 20-PLCC (9x9) |
|
PCI930PBKIC 3-1 ZOOM VIDEO SWITCH 128LQFP |
4,627 |
|
数据手册 |
- | Tube | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Surface Mount | 128-LQFP (14x14) |
|
|
HI9P0381-5IC MUX 50OHM 14SOIC |
1,461 |
|
数据手册 |
- | Bulk | Active | - | - | - | 50Ohm | - | 44V | ±22V | 300ns, 250ns | - | - | 16pF, 14pF | 5nA | - | 0°C ~ 75°C | - | - | Surface Mount | 14-SOIC |
|
ADG659YRQIC SWITCH SP4T X 2 75OHM 16QSOP |
2,951 |
|
数据手册 |
- | Tube | Obsolete | SP4T | 4:1 | 2 | 75Ohm | 1.3Ohm | 2V ~ 12V | ±2V ~ 6V | 115ns, 45ns | 400MHz | 2pC | 4pF, 12pF | 200pA | -90dB @ 1MHz | -40°C ~ 125°C (TA) | - | - | Surface Mount | 16-QSOP |
