固定电感器
| 图片 | 制造商型号 | 库存情况 | 数量 | 数据手册 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
B82141A1123K000FIXED IND 12UH 385MA 670 MOHM TH EPCOS - TDK Electronics |
2,986 |
|
数据手册 |
SBC | Axial | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 12 µH | ±10% | 385 mA | - | Unshielded | 670mOhm Max | 55 @ 2.52MHz | 20MHz | - | -55°C ~ 125°C | 2.52 MHz | - | Through Hole | - | 0.118" Dia x 0.268" L (3.00mm x 6.80mm) | - |
|
B82144B1475J000FIXED IND 4.7MH 120MA 21 OHM TH EPCOS - TDK Electronics |
2,971 |
|
数据手册 |
LBC | Radial, Vertical Cylinder | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 4.7 mH | ±5% | 120 mA | - | Unshielded | 21Ohm Max | 60 @ 252kHz | 1.1MHz | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 0.256" Dia (6.50mm) | 0.571" (14.50mm) |
|
|
B82144B1333J000FIXED IND 33UH 1.1A 350 MOHM TH EPCOS - TDK Electronics |
2,919 |
|
数据手册 |
LBC | Radial, Vertical Cylinder | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 33 µH | ±5% | 1.1 A | - | Unshielded | 350mOhm Max | 40 @ 2.52MHz | 8MHz | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 0.256" Dia (6.50mm) | 0.571" (14.50mm) |
.jpg)
|
B82422H1683J000FIXED IND 68UH 180MA 3.4 OHM SMD EPCOS - TDK Electronics |
3,846 |
|
数据手册 |
SIMID | 2-SMD, J-Lead | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 68 µH | ±5% | 180 mA | - | Unshielded | 3.4Ohm Max | 15 @ 2.52MHz | 10MHz | AEC-Q200 | -55°C ~ 150°C | 2.52 MHz | - | Surface Mount | 1210 (3225 Metric) | 0.126" L x 0.098" W (3.20mm x 2.50mm) | 0.094" (2.40mm) |
|
B82144F1475J000FIXED IND 4.7MH 120MA 21OHM TH EPCOS - TDK Electronics |
2,217 |
|
数据手册 |
B82144F1 | Axial | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 4.7 mH | ±5% | 120 mA | - | Unshielded | 21Ohm Max | 60 @ 252kHz | 1.1MHz | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 0.256" Dia x 0.362" L (6.50mm x 9.20mm) | - |
|
B82141A1392K009FIXED IND 3.9UH 560MA 320MOHM TH EPCOS - TDK Electronics |
5,000 |
|
数据手册 |
SBC | Axial | Cut Tape (CT) | Active | Drum Core, Wirewound | Ferrite | 3.9 µH | ±10% | 560 mA | - | Unshielded | 320mOhm Max | 50 @ 7.96MHz | 70MHz | - | -55°C ~ 125°C | 7.96 MHz | - | Through Hole | - | 0.118" Dia x 0.268" L (3.00mm x 6.80mm) | - |
|
B82141A1183K000FIXED IND 18UH 350MA 810 MOHM TH EPCOS - TDK Electronics |
4,500 |
|
数据手册 |
SBC | Axial | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 18 µH | ±10% | 350 mA | - | Unshielded | 810mOhm Max | 55 @ 2.52MHz | 14MHz | - | -55°C ~ 125°C | 2.52 MHz | - | Through Hole | - | 0.118" Dia x 0.268" L (3.00mm x 6.80mm) | - |
|
B82144F2823J000FIXED IND 82UH 1.4A 0.4OHM TH EPCOS - TDK Electronics |
2,692 |
|
数据手册 |
LBC | Axial | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 82 µH | ±5% | 1.4 A | 1.1A | Unshielded | 400mOhm Max | 40 @ 79.6kHz | 6MHz | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 0.256" Dia x 0.362" L (6.50mm x 9.20mm) | - |
|
B82145A1334J000FIXED IND 330UH 630MA 1.3 OHM TH EPCOS - TDK Electronics |
4,997 |
|
数据手册 |
HLBC | Axial | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 330 µH | ±5% | 630 mA | - | Unshielded | 1.3Ohm Max | 30 @ 796kHz | 2.1MHz | - | -55°C ~ 125°C | 100 kHz | - | Through Hole | - | 0.256" Dia x 0.472" L (6.50mm x 12.00mm) | - |
|
B82498F3470G001FIXED IND 47NH 600MA 130MOHM SMD EPCOS - TDK Electronics |
11,986 |
|
数据手册 |
SIMID | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ceramic | 47 nH | ±2% | 600 mA | - | Unshielded | 130mOhm Max | 65 @ 500MHz | 2GHz | - | -55°C ~ 125°C | 200 MHz | - | Surface Mount | 0805 (2012 Metric) | 0.091" L x 0.067" W (2.30mm x 1.70mm) | 0.055" (1.40mm) |
