固定电感器
| 图片 | 制造商型号 | 库存情况 | 数量 | 数据手册 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CSHB0412-1R5MFIX IND 1.5UH 4.8A 52.5MOHM SMD CODACA |
2,230 |
|
数据手册 |
CSHB0412 | Nonstandard | Cut Tape (CT) | Active | - | Alloy Powder | 1.5 µH | ±20% | 4.8 A | 4.8A | Shielded | 52.5mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.173" L x 0.165" W (4.40mm x 4.20mm) | 0.047" (1.20mm) |
|
CSBL0650-2R0MSMD HIGH CURRENT POWER INDUCTOR CODACA |
500 |
|
数据手册 |
CSBL0650 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Metal Composite | 2 µH | ±20% | 11.8 A | 14A | Shielded | 6.4mOhm Max | - | - | AEC-Q200 | -50°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.276" L x 0.272" W (7.00mm x 6.90mm) | 0.197" (5.00mm) |
|
|
CSAB1250A-R15MFIX IND 0.15UH 50A 0.60MOHM SMD CODACA |
100 |
|
数据手册 |
CSAB1250A | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 150 nH | ±20% | 50 A | 75A | Shielded | 600µOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.543" L x 0.496" W (13.80mm x 12.60mm) | 0.197" (5.00mm) |
|
|
CSAB1250A-R33MFIX IND 0.33UH 41A 1.00MOHM SMD CODACA |
100 |
|
数据手册 |
CSAB1250A | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 330 nH | ±20% | 41 A | 60A | Shielded | 1mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.543" L x 0.496" W (13.80mm x 12.60mm) | 0.197" (5.00mm) |
|
|
CSAB1250A-1R5MFIX IND 1.5UH 22A 3.20MOHM SMD CODACA |
100 |
|
数据手册 |
CSAB1250A | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 1.5 µH | ±20% | 22 A | 33A | Shielded | 3.2mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.543" L x 0.496" W (13.80mm x 12.60mm) | 0.197" (5.00mm) |
|
|
CSAB1250A-R22MFIX IND 0.22UH 50A 0.80MOHM SMD CODACA |
100 |
|
数据手册 |
CSAB1250A | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 220 nH | ±20% | 50 A | 70A | Shielded | 0.8mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.543" L x 0.496" W (13.80mm x 12.60mm) | 0.197" (5.00mm) |
|
|
CSAB1250A-R80MFIX IND 0.8UH 26.5A 2.00MOHM SMD CODACA |
4,002 |
|
数据手册 |
CSAB1250A | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 800 nH | ±20% | 26.5 A | 40A | Shielded | 2mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.543" L x 0.496" W (13.80mm x 12.60mm) | 0.197" (5.00mm) |
|
|
CSAB1250A-R68MFIX IND 0.68UH 28.5A 1.90MOHM SM CODACA |
3,536 |
|
数据手册 |
CSAB1250A | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 680 nH | ±20% | 28.5 A | 40A | Shielded | 1.9mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.543" L x 0.496" W (13.80mm x 12.60mm) | 0.197" (5.00mm) |
|
|
CSAB1260A-1R5MFIX IND 1.5UH 27.5A 2.90MOHM SMD CODACA |
100 |
|
数据手册 |
CSAB1260A | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 1.5 µH | ±20% | 27.5 A | 28A | Shielded | 2.9mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.543" L x 0.496" W (13.80mm x 12.60mm) | 0.236" (6.00mm) |
|
|
CSAB1260A-1R0MFIX IND 1UH 30.5A 2.10MOHM SMD CODACA |
100 |
|
数据手册 |
CSAB1260A | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 1 µH | ±20% | 30.5 A | 31A | Shielded | 2.1mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.543" L x 0.496" W (13.80mm x 12.60mm) | 0.236" (6.00mm) |
