直流无刷风扇（BLDC）
| 图片 | 制造商型号 | 库存情况 | 数量 | 数据手册 | 系列 | 包装 | 产品状态 | 额定电压 | 尺寸 / 尺寸 | 宽度 | 气流 | 静压 | 轴承类型 | 风扇类型 | 特性 | 噪音 | 功率（瓦特） | 转速（RPM） | 端接方式 | 防护等级 | 工作温度 | 认证机构 | 重量 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CBM-9330B-240-507DC BLOWER, 92.3 X 92.6 X 30 MM, Same Sky (Formerly CUI Devices) |
3,188 |
|
数据手册 |
CBM-93B | Box | Active | 24VDC | Rectangular/Rounded - 92.5mm L x 92.3mm H | 29.50mm | 21.7 CFM (0.608m³/min) | 1.140 in H2O (284.0 Pa) | Ball | Blower | Auto Restart | 47.5dB(A) | 7.2 W | 3500 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
CBM-7530CF-250-493DC BLOWER, 49.2 X 49.8 X 20 MM, Same Sky (Formerly CUI Devices) |
1,898 |
|
数据手册 |
CBM-75CF | Box | Active | 24VDC | Square/Rounded - 75.7mm L x 75.7mm H | 24.50mm | 14.7 CFM (0.412m³/min) | 0.850 in H2O (211.7 Pa) | omniCOOL™ Magnetic Sleeve | Blower | Auto Restart | 49.3dB(A) | 10.8 W | 5000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CFM-9232S-250-509-20FAN AXIAL 92.2X32MM 24VDC WIRE Same Sky (Formerly CUI Devices) |
4,453 |
|
数据手册 |
CFM-92S | Box | Active | 24VDC | Square - 92.2mm L x 92.2mm H | 32.00mm | 102.8 CFM (2.91m³/min) | 0.620 in H2O (154.4 Pa) | Sleeve | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 51.0dB(A) | 13.2 W | 5000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
CFM-9238S-148-523-20FAN AXIAL 92X37.5MM 12VDC WIRE Same Sky (Formerly CUI Devices) |
3,570 |
|
数据手册 |
CFM-92S | Box | Active | 12VDC | Square - 92mm L x 92mm H | 37.50mm | 92.0 CFM (2.58m³/min) | 0.630 in H2O (156.9 Pa) | Sleeve | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 52.3dB(A) | 11.4 W | 4800 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CFM-4028BG-1160-520-20FAN AXIAL 40X28MM 12VDC WIRE Same Sky (Formerly CUI Devices) |
4,132 |
|
数据手册 |
CFM-40BG | Box | Active | 12VDC | Square - 40mm L x 40mm H | 28.00mm | 19.5 CFM (0.546m³/min) | 1.560 in H2O (388.6 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 52.0dB(A) | 6.48 W | 16000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
CBM-9330B-140-507-20DC BLOWER, 92.3 X 92.6 X 30 MM, Same Sky (Formerly CUI Devices) |
3,831 |
|
数据手册 |
CBM-93B | Box | Active | 12VDC | Rectangular/Rounded - 92.5mm L x 92.3mm H | 29.50mm | 21.4 CFM (0.599m³/min) | 1.290 in H2O (321.3 Pa) | Ball | Blower | Auto Restart, Speed Sensor (Tach) | 47.8dB(A) | 6.36 W | 3500 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
CFM-6025BG-235-253-22DC AXIAL FAN, 60 MM SQUARE, 25 M Same Sky (Formerly CUI Devices) |
4,574 |
|
数据手册 |
CFM-60BG | Box | Active | 24VDC | Square - 60mm L x 60mm H | 25.00mm | 14.7 CFM (0.412m³/min) | 0.150 in H2O (37.4 Pa) | Ball | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 25.3dB(A) | 0.96 W | 3500 RPM | 4 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
CBM-979433B-230-507-22FAN BLOWER 97.68X32.7MM 24VDC Same Sky (Formerly CUI Devices) |
1,815 |
|
数据手册 |
CBM-97B-2 | Box | Active | 24VDC | Rectangular/Rounded - 97.68mm L x 94.18mm H | 32.70mm | 20.5 CFM (0.574m³/min) | 0.660 in H2O (164.4 Pa) | Ball | Blower | Auto Restart, PWM Control, Speed Sensor (Tach) | 50.7dB(A) | 8.4 W | 3000 RPM | 4 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
CBM-7530CF-250-493-20DC BLOWER, 49.2 X 49.8 X 20 MM, Same Sky (Formerly CUI Devices) |
3,060 |
|
数据手册 |
CBM-75CF | Box | Active | 24VDC | Square/Rounded - 75.7mm L x 75.7mm H | 24.50mm | 14.7 CFM (0.412m³/min) | 0.850 in H2O (211.7 Pa) | omniCOOL™ Magnetic Sleeve | Blower | Auto Restart, Speed Sensor (Tach) | 49.3dB(A) | 10.8 W | 5000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
CFM-6025BG-2130-606DC AXIAL FAN, 60 MM SQUARE, 25 M Same Sky (Formerly CUI Devices) |
2,077 |
|
数据手册 |
CFM-60BG | Box | Active | 24VDC | Square - 60mm L x 60mm H | 25.00mm | 56.7 CFM (1.59m³/min) | 1.980 in H2O (493.2 Pa) | Ball | Tubeaxial | Auto Restart | 60.6dB(A) | 19.2 W | 13000 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
