交流直流桌面、墙式电源适配器
| 图片 | 制造商型号 | 库存情况 | 数量 | 数据手册 | 系列 | 包装 | 产品状态 | 使用区域 | 形式 | 输入类型 | 电压 - 输入 | 电压 - 输出 | 电流 - 输出（最大值） | 功率（瓦特） | 空载功耗 | 极化 | 应用 | 效率 | 工作温度 | 输出连接器 | 电线长度 | 输入连接器 | 特性 | 尺寸 / 尺寸 | 认证机构 | 标准编号 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ACM36US30AC/DC WALL MOUNT ADAPTER 30V 36W |
4,352 |
|
数据手册 |
ACM36 (36W) | Box | Active | International | Wall Mount (Class II) | Multi-Blade (Sold Separately) | 90 ~ 264 VAC | 30V | 1.2A | 36 W | 75mW (Max) | - | ITE (Commercial), Medical | Level VI, CoC Tier 2 | 0°C ~ 60°C | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 11.0mm | 59" (1.50m) | Multi-Blade (Sold Separately) | - | 3.93" L x 1.29" W x 2.34" H (96.7mm x 33.0mm x 59.5mm) | CB, CE, CSA, TUV, UL | |
|
TRH25150-A-01E03 VIAC/DC WALL MOUNT ADAPTER 15V 25W |
3,167 |
|
数据手册 |
TRH25 (25W) | Box | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 90 ~ 264 VAC | 15V | 1.67A | 25 W | 75mW (Max) | - | ITE (Commercial) | Level VI, CoC Tier 2 | -20°C ~ 60°C | - | 70.9" (1.80m) | NEMA 1-15P | - | 2.84" L x 1.38" W x 2.05" H (72.0mm x 35.0mm x 52.0mm) | CE, cULus, GS, TUV | |
|
SDI30-15-U-P5AC/DC DESKTOP ADAPTER 15V 30W |
1,947 |
|
数据手册 |
SDI30-U (30W) | Bulk | Obsolete | International | Desktop (Class I) | Cord (Sold Separately) | 90 ~ 264 VAC | 15V | 2A | 30 W | 75mW (Max) | Positive Center | ITE (Commercial) | Level VI | 0°C ~ 40°C | Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 9.5mm | 60.2" (1.53m) | IEC 320-C14 | - | 4.37" L x 2.05" W x 1.27" H (111.0mm x 52.0mm x 32.3mm) | CB Scheme, CCC, CSA, EN, FCC, IEC, RCM, SIQ, TUV, UL | |
|
6A-181WP05-127AC/DC WALL MOUNT ADAPTER 5V |
2,994 |
|
数据手册 |
6A-181WP05 (18W) | Box | Active | International | Wall Mount (Class II) | Multi-Blade (Included) | 90 ~ 264 VAC | 5V | 3A | - | 100mW (Max) | Positive Center | ITE (Commercial) | Level VI | 0°C ~ 40°C | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm | 39.4" (1.00m) | Multi-Blade | - | 2.90" L x 1.71" W x 1.39" H (74.0mm x 43.5mm x 35.3mm) | AS/NZS, BIS, BSMI, CB, CCC, CSA, FCC, IEC, KC, PSE, RCM, UKCA, UL | |
|
P12W12VAC/DC WALL MOUNT ADAPTER 12V 12W |
2,241 |
|
数据手册 |
- | Box | Active | North America | Wall Mount (Class II) | Fixed Blade | 120VAC | 12V | 1A | 12 W | - | - | ITE (Commercial) | - | - | - | 72.83" (1.85m) | NEMA 1-15P | - | 3.38" L x 1.88" W x 1.50" H (85.7mm x 47.6mm x 38.1mm) | - | |
|
P12W24VAC/DC WALL MOUNT ADAPTER 24V 12W |
4,250 |
|
数据手册 |
- | Box | Active | North America | Wall Mount (Class II) | Fixed Blade | 120VAC | 24V | 500mA | 12 W | - | - | ITE (Commercial) | - | - | - | 72.83" (1.85m) | NEMA 1-15P | - | 3.38" L x 1.88" W x 1.50" H (85.7mm x 47.6mm x 38.1mm) | - | |
|
6A-181WP12-187AC/DC WALL MOUNT ADAPTER 12V |
1,865 |
|
数据手册 |
6A-181WP12 (18W) | Box | Active | International | Wall Mount (Class II) | Multi-Blade (Included) | 90 ~ 264 VAC | 12V | 1.5A | - | 100mW (Max) | Positive Center | ITE (Commercial) | Level VI | 0°C ~ 40°C | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm | 60.2" (1.53m) | Multi-Blade | - | 2.90" L x 1.71" W x 1.39" H (74.0mm x 43.5mm x 35.3mm) | AS/NZS, BIS, BSMI, CB, CCC, CSA, FCC, IEC, KC, PSE, RCM, UKCA, UL | |
|
AMA65UR5-120500YAC/DC WALL MOUNT ADAPTER 12V 60W |
4,599 |
|
数据手册 |
AMA65-Y | Box | Active | North America | Wall Mount (Class II) | Fixed Blade | 90 ~ 264 VAC | 12V | 5A | 60 W | 210mW (Max) | Positive Center | ITE (Commercial) | Level VI, CoC Tier 2 | 0°C ~ 40°C | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm | 60.2" (1.50m) | NEMA 1-15P | - | 4.15" L x 1.65" W x 3.41" H (105.4mm x 42.0mm x 86.5mm) | CE, UL | |
|
RR9LH3610T00-IMR6BAC/DC DSKTP/WALL MT ADPT 18V 65W |
3,078 |
|
数据手册 |
- | Bulk | Active | International | Desktop, Wall Mount (Class I) | Cord, Multi-Blade (Sold Separately) | 90 ~ 264 VAC | 18V | 3.61A | 65 W | 150mW (Max) | Negative Center | ITE (Commercial), Medical | Level VI, CoC Tier 2 | -20°C ~ 40°C | Barrel Plug Kit, (1.3mm x 3.5mm, 2.1mm x 5.5mm, 2.5mm x 5.5mm) | 47.2" (1.20m) | IEC 320-C6, Multi-Blade (Sold Separately) | - | 4.63" L x 2.11" W x 1.44" H (117.5mm x 53.5mm x 36.6mm) | CB, CE, cETLus, EAC, ETL, FCC, PSE, S-Mark, UKRSepro, VCCI | |
|
RR9LX1350T00-IMR6BAC/DC DSKTP/WALL MT ADPT 48V 65W |
1,451 |
|
数据手册 |
- | Bulk | Active | International | Desktop, Wall Mount (Class I) | Cord, Multi-Blade (Sold Separately) | 90 ~ 264 VAC | 48V | 1.35A | 65 W | 150mW (Max) | Positive Tip, Negative Sleeve | ITE (Commercial), Medical | Level VI, CoC Tier 2 | -20°C ~ 40°C | Barrel Plug Kit, (1.3mm x 3.5mm, 2.1mm x 5.5mm, 2.5mm x 5.5mm) | 59" (1.50m) | IEC 320-C6, Multi-Blade (Sold Separately) | - | 4.63" L x 2.11" W x 1.44" H (117.5mm x 53.5mm x 36.6mm) | CB, CE, cETLus, EAC, ETL, FCC, PSE, S-Mark, UKRSepro, VCCI | |
|
RR9LG4330T00-IMR6BAC/DC DSKTP/WALL MT ADPT 15V 65W |
2,393 |
|
数据手册 |
- | Bulk | Active | International | Desktop, Wall Mount (Class I) | Cord, Multi-Blade (Sold Separately) | 90 ~ 264 VAC | 15V | 4.33A | 65 W | 150mW (Max) | Negative Center | ITE (Commercial), Medical | Level VI, CoC Tier 2 | -20°C ~ 40°C | Barrel Plug Kit, (1.3mm x 3.5mm, 2.1mm x 5.5mm, 2.5mm x 5.5mm) | 47.2" (1.20m) | IEC 320-C6, Multi-Blade (Sold Separately) | - | 4.63" L x 2.11" W x 1.44" H (117.5mm x 53.5mm x 36.6mm) | CB, CE, cETLus, EAC, ETL, FCC, PSE, S-Mark, UKRSepro, VCCI | |
|
SDI40-12-UD-P5AC/DC DESKTOP ADAPTER 12V 36W |
2,522 |
|
数据手册 |
SDI40-UD (40W) | Bulk | Obsolete | International | Desktop (Class II) | Cord (Sold Separately) | 90 ~ 264 VAC | 12V | 3A | 36 W | 75mW (Max) | Positive Center | ITE (Commercial) | Level VI | 0°C ~ 40°C | Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 9.5mm | 60.2" (1.53m) | IEC 320-C8 | - | 4.37" L x 2.05" W x 1.27" H (111.0mm x 52.0mm x 32.3mm) | CE, cULus, GS, PSE | |
|
TR9KZ3160LCPCIMR6BAC/DC DESKTOP ADAPTER 19V 60W |
2,095 |
|
数据手册 |
GTM96600-6019-T2 | Bulk | Active | International | Desktop (Class II) | Cord (Sold Separately) | 90 ~ 264 VAC | 19V | 3.16A | 60 W | 150mW (Max) | Positive Center | Household Appliances, ITE (Commercial), Medical | Level VI, CoC Tier 2 | -20°C ~ 40°C | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 11.0mm | 60.2" (1.53m) | IEC 320-C8 | - | 4.63" L x 2.11" W x 1.35" H (117.5mm x 53.5mm x 34.2mm) | BSMI, CB, CCC, CE, cETLus, EAC, ETL, FCC, LPS, PSE, RCM, S-Mark, UKRSepro, VCCI | |
|
IPD3019-760SAC/DC DESKTOP ADAPTER 19V |
4,469 |
|
数据手册 |
IPD30 (30W) | Box | Active | North America | Desktop (Class I) | Cord (Sold Separately) | 85 ~ 264 VAC | 19V | 1.6A | - | 100mW (Max) | Positive Center | ITE (Commercial) | Level VI | 0°C ~ 60°C | Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 9.5mm | 48" (1.22m) | IEC 320-C6 | - | 3.53" L x 1.92" W x 0.99" H (89.6mm x 48.8mm x 25.2mm) | CE, cTUVus | |
|
AMA36UR5-120300YAC/DC WALL MOUNT ADAPTER 12V 36W |
2,852 |
|
数据手册 |
AMA36-Y | Box | Active | North America | Wall Mount (Class II) | Fixed Blade | 90 ~ 264 VAC | 12V | 3A | 36 W | 75mW (Max) | Positive Center | ITE (Commercial) | Level VI | 0°C ~ 40°C | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm | 60.2" (1.50m) | NEMA 1-15P | - | 3.27" L x 1.38" W x 2.97" H (83.0mm x 35.0mm x 75.5mm) | CE, UL | |
|
GE40I24-P1JAC/DC WALL MOUNT ADAPTER 24V 40W |
1,769 |
|
数据手册 |
GE40 (40W) | Box | Obsolete | International | Wall Mount (Class II) | Multi-Blade (Sold Separately) | 90 ~ 264 VAC | 24V | 1.67A | 40 W | 75mW (Max) | Positive Center | ITE (Commercial) | Level VI, CoC Tier 2 | -30°C ~ 70°C | Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 11.0mm | 59" (1.50m) | Multi-Blade | - | 3.70" L x 1.91" W x 1.57" H (94.0mm x 48.4mm x 40.0mm) | CCC, CE, cULus, EAC, FCC, GS, RCM, TUV | |
|
MWA020005B-10AAC/DC DESKTOP ADAPTER 5V 20W |
4,456 |
|
数据手册 |
MWA020 (20W) | Bulk | Active | International | Desktop (Class II) | Cord (Sold Separately) | 85 ~ 264 VAC | 5V | 4A | 20 W | 300mW (Max) | Positive Center | Medical | Level V | 0°C ~ 40°C | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm | 72" (1.83m) | IEC 320-C8 | - | 3.45" L x 2.04" W x 1.30" H (87.7mm x 51.8mm x 33.0mm) | CB, CE, cTUVus | |
|
FWA020012B-10AAC/DC DESKTOP ADAPTER 12V 20W |
3,016 |
|
数据手册 |
FWA020 (20W) | Bulk | Active | International | Desktop (Class II) | Cord (Sold Separately) | 85 ~ 264 VAC | 12V | 1.67A | 20 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level VI | 0°C ~ 60°C | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 9.5mm | 48" (1.22m) | IEC 320-C8 | - | 3.45" L x 2.04" W x 1.30" H (87.7mm x 51.8mm x 33.0mm) | CB, CE, cTUVus | |
|
TRG36A18-01E03 VIAC/DC DESKTOP ADAPTER 18V 36W |
2,746 |
|
数据手册 |
TRG36 (36W) | Box | Obsolete | International | Desktop (Class II) | Cord (Sold Separately) | 90 ~ 264 VAC | 18V | 2A | 36 W | 75mW (Max) | Positive Center | ITE (Commercial) | Level VI, CoC Tier 2 | -20°C ~ 60°C | Barrel Plug R/A, 2.1mm I.D. x 5.5mm O.D. x 12.0mm | 70.9" (1.80m) | IEC 320-C8 | - | 4.37" L x 2.01" W x 0.89" H (111.0mm x 51.0mm x 22.5mm) | CE, cULus, FCC, GS, PSE, TUV | |
|
TRG36A15-11E03 VIAC/DC DESKTOP ADAPTER 15V 36W |
4,928 |
|
数据手册 |
TRG36 (36W) | Box | Obsolete | International | Desktop (Class II) | Cord (Sold Separately) | 90 ~ 264 VAC | 15V | 2.4A | 36 W | 75mW (Max) | Positive Center | ITE (Commercial) | Level VI, CoC Tier 2 | -20°C ~ 60°C | Barrel Plug R/A, 2.1mm I.D. x 5.5mm O.D. x 12.0mm | 70.9" (1.80m) | IEC 320-C8 | - | 4.37" L x 2.01" W x 0.89" H (111.0mm x 51.0mm x 22.5mm) | CE, cULus, FCC, GS, PSE, TUV |
