交流直流转换器
| 图片 | 制造商型号 | 库存情况 | 数量 | 数据手册 | 系列 | 包装 | 产品状态 | 类型 | 输出数量 | 电压 - 输入 | 电压 - 输出 1 | 电压 - 输出 2 | 电压 - 输出 3 | 电压 - 输出 4 | 电压 - 输出 5 | 电压 - 输出 6 | 电流 - 输出 1 | 电流 - 输出 2 | 电流 - 输出 3 | 电流 - 输出 4 | 电流 - 输出 5 | 电流 - 输出 6 | 功率（瓦特） | 应用 | 电压 - 隔离 | 效率 | 工作温度 | 特性 | 安装类型 | 尺寸 / 尺寸 | 认证机构 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MBC150-1012GAC/DC CONVERTER 12V 110/150W |
3,150 |
|
数据手册 |
MBC150 (150W) | Box | Obsolete | Open Frame | 1 | 90 ~ 264 VAC | 12V | - | - | - | - | - | 8.33 A | - | - | - | - | - | 110W (150W Forced Air) | Medical | 5.9 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Standby Output, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.32" H (101.6mm x 50.8mm x 33.6mm) | ||
|
|
MBC150-1024GAC/DC CONVERTER 24V 110W |
4,490 |
|
数据手册 |
MBC150 (150W) | Box | Obsolete | Open Frame | 1 | 90 ~ 264 VAC | 24V | - | - | - | - | - | 4.17 A | - | - | - | - | - | 110W (150W Forced Air) | Medical | 5.9 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Standby Output, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.32" H (101.6mm x 50.8mm x 33.6mm) | ||
|
ATX-0250GAAC/DC CNVT 3.3V 5V 2X12V -12V |
1,710 |
|
数据手册 |
- | Bulk | Active | ATX | 5 | 90 ~ 264 VAC | 3.3V | 5V | 12V | 12V | -12V | - | 24 A | 20 A | 20 A | 20 A | 300 mA | - | 663W | ITE (Commercial) | - | 0°C ~ 40°C | PFC, Standby Output, Universal Input | Benchtop | 5.90" L x 5.50" W x 3.38" H (149.9mm x 139.7mm x 85.9mm) | ||
|
AA15D1515CAC/DC CONVERTER +/-15V 15W |
234 |
|
数据手册 |
AA15D (15W) | Box | Obsolete | Enclosed | 2 | 85 ~ 264 VAC | 15V | -15V | - | - | - | - | 500 mA | 500 mA | - | - | - | - | 15W | ITE (Commercial) | 3 kV | -25°C ~ 70°C | DC Input Capable, Universal Input | Chassis Mount | 2.91" L x 2.13" W x 0.77" H (74.0mm x 54.0mm x 19.5mm) | ||
|
1011268GRN-45-2002 |
3,721 |
|
数据手册 |
GRN-45 (45W) | Box | Active | Open Frame | 2 | 85 ~ 264 VAC | 5V | 12V | - | - | - | - | 5 A | 2 A | - | - | - | - | 45W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.25" L x 2.50" W x 0.83" H (108.0mm x 63.5mm x 21.1mm) | ||
|
1010427CHCOSRP-25-1004 CHCO |
2,414 |
|
数据手册 |
SRP-25 (25W) | Box | Active | Enclosed | 1 | 100 ~ 240 VAC | 15V | - | - | - | - | - | 1.67 A | - | - | - | - | - | 25W | Industrial, ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.21" L x 2.47" W x 1.40" H (106.9mm x 62.7mm x 35.6mm) | ||
|
|
1010428CHCOSRP-25-1005 CHCO |
3,909 |
|
数据手册 |
SRP-25 (25W) | Box | Active | Enclosed | 1 | 100 ~ 240 VAC | 24V | - | - | - | - | - | 1.04 A | - | - | - | - | - | 25W | Industrial, ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.21" L x 2.47" W x 1.40" H (106.9mm x 62.7mm x 35.6mm) | ||
|
|
1010426CHCOSRP-25-1003 CHCO |
3,304 |
|
数据手册 |
SRP-25 (25W) | Box | Active | Enclosed | 1 | 100 ~ 240 VAC | 12V | - | - | - | - | - | 2.08 A | - | - | - | - | - | 25W | Industrial, ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.21" L x 2.47" W x 1.40" H (106.9mm x 62.7mm x 35.6mm) | ||
|
|
1010429CHCOSRP-25-1006 CHCO |
3,791 |
|
数据手册 |
SRP-25 (25W) | Box | Active | Enclosed | 1 | 100 ~ 240 VAC | 48V | - | - | - | - | - | 520 mA | - | - | - | - | - | 25W | Industrial, ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.21" L x 2.47" W x 1.40" H (106.9mm x 62.7mm x 35.6mm) | ||
|
|
1010424CHCOSRP-25-1001 CHCO |
4,047 |
|
数据手册 |
SRP-25 (25W) | Box | Active | Enclosed | 1 | 100 ~ 240 VAC | 3.3V | - | - | - | - | - | 6 A | - | - | - | - | - | 20W | Industrial, ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.21" L x 2.47" W x 1.40" H (106.9mm x 62.7mm x 35.6mm) | ||
|
|
1010425CHCOSRP-25-1002 CHCO |
3,860 |
|
数据手册 |
SRP-25 (25W) | Box | Active | Enclosed | 1 | 100 ~ 240 VAC | 5V | - | - | - | - | - | 5 A | - | - | - | - | - | 25W | Industrial, ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 4.21" L x 2.47" W x 1.40" H (106.9mm x 62.7mm x 35.6mm) | ||
|
VGS-250B-48AC/DC CONVERTER 48V 250W |
4,369 |
|
数据手册 |
VGS-250B (250W) | Bulk | Obsolete | Enclosed | 1 | 90 ~ 132 VAC, 180 ~ 264 VAC | 48V | - | - | - | - | - | 5.2 A | - | - | - | - | - | 250W | ITE (Commercial) | 1.5 kV | -20°C ~ 70°C (With Derating) | Adjustable Output | Chassis Mount | 8.46" L x 4.53" W x 1.18" H (215.0mm x 115.0mm x 30.0mm) | ||
|
1011401CHGRN-60-1001 OVP CH |
2,158 |
|
数据手册 |
GRN-60 (60W) | Box | Active | Chassis | 1 | 85 ~ 264 VAC | 3.3V | - | - | - | - | - | 9 A | - | - | - | - | - | 30W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 3.20" L x 2.43" W x 1.28" H (81.3mm x 61.7mm x 32.5mm) | ||
|
1011336CHCOGRN-60-1006 CHCO |
2,213 |
|
数据手册 |
GRN-60 (60W) | Box | Active | Enclosed | 1 | 85 ~ 264 VAC | 28V | - | - | - | - | - | 2.2 A | - | - | - | - | - | 60W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 3.20" L x 2.43" W x 1.28" H (81.3mm x 61.7mm x 32.5mm) | ||
|
|
1011333CHCOGRN-60-1003 CHCO |
3,592 |
|
数据手册 |
GRN-60 (60W) | Box | Active | Enclosed | 1 | 85 ~ 264 VAC | 12V | - | - | - | - | - | 5 A | - | - | - | - | - | 60W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 3.20" L x 2.43" W x 1.28" H (81.3mm x 61.7mm x 32.5mm) | ||
|
|
1011403CHGRN-60-1003 OVP CH |
2,322 |
|
数据手册 |
GRN-60 (60W) | Box | Active | Chassis | 1 | 85 ~ 264 VAC | 12V | - | - | - | - | - | 5 A | - | - | - | - | - | 60W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 3.20" L x 2.43" W x 1.28" H (81.3mm x 61.7mm x 32.5mm) | ||
|
|
1011407CHGRN-60-1007 OVP CH |
3,833 |
|
数据手册 |
GRN-60 (60W) | Box | Active | Chassis | 1 | 85 ~ 264 VAC | 48V | - | - | - | - | - | 1.3 A | - | - | - | - | - | 60W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 3.20" L x 2.43" W x 1.28" H (81.3mm x 61.7mm x 32.5mm) | ||
|
|
1011335CHCOGRN-60-1005 CHCO |
3,201 |
|
数据手册 |
GRN-60 (60W) | Box | Active | Enclosed | 1 | 85 ~ 264 VAC | 24V | - | - | - | - | - | 2.5 A | - | - | - | - | - | 60W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 3.20" L x 2.43" W x 1.28" H (81.3mm x 61.7mm x 32.5mm) | ||
|
|
1011406CHGRN-60-1006 OVP CH |
3,505 |
|
数据手册 |
GRN-60 (60W) | Box | Active | Chassis | 1 | 85 ~ 264 VAC | 28V | - | - | - | - | - | 2.2 A | - | - | - | - | - | 60W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 3.20" L x 2.43" W x 1.28" H (81.3mm x 61.7mm x 32.5mm) | ||
|
|
1011360CHCOGRN-60-1008 CHCO |
2,922 |
|
数据手册 |
GRN-60 (60W) | Box | Active | Enclosed | 1 | 85 ~ 264 VAC | 19V | - | - | - | - | - | 3.1 A | - | - | - | - | - | 60W | ITE (Commercial), Medical | - | 0°C ~ 70°C (With Derating) | Adjustable Output, Remote Sense, Universal Input | Chassis Mount | 3.20" L x 2.43" W x 1.28" H (81.3mm x 61.7mm x 32.5mm) |
