交流直流转换器
| 图片 | 制造商型号 | 库存情况 | 数量 | 数据手册 | 系列 | 包装 | 产品状态 | 类型 | 输出数量 | 电压 - 输入 | 电压 - 输出 1 | 电压 - 输出 2 | 电压 - 输出 3 | 电压 - 输出 4 | 电压 - 输出 5 | 电压 - 输出 6 | 电流 - 输出 1 | 电流 - 输出 2 | 电流 - 输出 3 | 电流 - 输出 4 | 电流 - 输出 5 | 电流 - 输出 6 | 功率（瓦特） | 应用 | 电压 - 隔离 | 工作温度 | 特性 | 安装类型 | 尺寸 / 尺寸 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RWS150B-12/CO2AC/DC CONVERTER 12V 150W TDK-Lambda |
1,544 |
|
数据手册 |
RWS-B (150W) | Bulk | Active | Enclosed, Conformal Coated | 1 | 85 ~ 265 VAC | 12V | - | - | - | - | - | 13 A | - | - | - | - | - | 150W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 5.04" L x 3.70" W x 1.61" H (128.0mm x 94.0mm x 41.0mm) |
|
|
RWS150B-24/CO2AC/DC CONVERTER 24V 150W TDK-Lambda |
1,338 |
|
数据手册 |
RWS-B (150W) | Bulk | Active | Enclosed, Conformal Coated | 1 | 85 ~ 265 VAC | 24V | - | - | - | - | - | 6.5 A | - | - | - | - | - | 150W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 5.04" L x 3.70" W x 1.61" H (128.0mm x 94.0mm x 41.0mm) |
|
MTW60-51515-VAC/DC CONVERTER 5V +/-15V 60W TDK-Lambda |
3,721 |
|
数据手册 |
MTW (60W) | Bulk | Active | Open Frame | 3 | 85 ~ 265 VAC | 5V | 15V | -15V | - | - | - | 5 A | 2 A | 500 mA | - | - | - | 60W | ITE (Commercial) | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, PFC, Universal Input | Chassis Mount | 7.28" L x 3.27" W x 1.02" H (185.0mm x 83.0mm x 26.0mm) |
|
CUT75-522/TAC/DC CONVERTER 5V +/-12V 75W TDK-Lambda |
1,144 |
|
数据手册 |
CUT75 (75W) | Bulk | Active | Open Frame | 3 | 85 ~ 265 VAC | 5V | 12V | -12V | - | - | - | 8 A | 3 A | 1 A | - | - | - | 75W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.06" H (127.0mm x 76.2mm x 26.9mm) |
|
VS75E-12AC/DC CONVERTER 6X12V 76W TDK-Lambda |
4,174 |
|
数据手册 |
VS-E (150W) | Box | Active | Open Frame | 6 | 85 ~ 132 VAC | 12V | 12V | 12V | 12V | 12V | 12V | 6.3 A | 6.3 A | 6.3 A | 6.3 A | 6.3 A | 6.3 A | 76W | ITE (Commercial) | 2 kV | -10°C ~ 70°C (With Derating) | Adjustable Output | Chassis Mount | 5.91" L x 1.97" W x 1.14" H (150.1mm x 50.0mm x 29.0mm) |
|
ZWS100BAF-15/LAC/DC CONVERTER 15V 100W TDK-Lambda |
3,148 |
|
数据手册 |
ZWS100BAF (100W) | Bulk | Active | Open Frame | 1 | 85 ~ 265 VAC | 15V | - | - | - | - | - | 6.7 A | - | - | - | - | - | 100W | ITE (Commercial) | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 6.10" L x 2.44" W x 1.30" H (155.0mm x 62.0mm x 33.0mm) |
|
|
CUT75-5FF/TBAC/DC CONVERTER 5V +/-15V 75W TDK-Lambda |
3,875 |
|
数据手册 |
CUT75 (75W) | Bulk | Active | Open Frame | 3 | 85 ~ 265 VAC | 5V | 15V | -15V | - | - | - | 8 A | 2.5 A | 1 A | - | - | - | 75W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Baseplate, DC Input Capable, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.06" H (127.0mm x 76.2mm x 26.9mm) |
|
|
CUT75-5FF/BAC/DC CONVERTER 5V +/-15V 75W TDK-Lambda |
1,839 |
|
数据手册 |
CUT75 (75W) | Bulk | Active | Open Frame | 3 | 85 ~ 265 VAC | 5V | 15V | -15V | - | - | - | 8 A | 2.5 A | 1 A | - | - | - | 75W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Baseplate, DC Input Capable, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.06" H (127.0mm x 76.2mm x 26.9mm) |
|
|
CUT75-522/BAC/DC CONVERTER 5V +/-12V 75W TDK-Lambda |
4,298 |
|
数据手册 |
CUT75 (75W) | Bulk | Active | Open Frame | 3 | 85 ~ 265 VAC | 5V | 12V | -12V | - | - | - | 8 A | 3 A | 1 A | - | - | - | 75W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Baseplate, DC Input Capable, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.06" H (127.0mm x 76.2mm x 26.9mm) |
|
|
CUT75-522/TBAC/DC CONVERTER 5V +/-12V 75W TDK-Lambda |
2,917 |
|
数据手册 |
CUT75 (75W) | Bulk | Active | Open Frame | 3 | 85 ~ 265 VAC | 5V | 12V | -12V | - | - | - | 8 A | 3 A | 1 A | - | - | - | 75W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Baseplate, DC Input Capable, Universal Input | Chassis Mount | 5.00" L x 3.00" W x 1.06" H (127.0mm x 76.2mm x 26.9mm) |
